3 Components and Power Supply
E
F
G
H
I
J
K
L
M
N
O
8
Eth WAN-1 SFP.
For more information on the SFP interface, refer to:
- WAN connections on page 15
- WAN SFP connector on page 29
- WAN SFP interface on page 31
Eth WAN-2 Base-T. WAN Gigabit Ethernet.
For more information on the WAN interface, refer to:
- WAN connections on page 15
- WAN Base-T connector on page 29
- WAN Base-T interface on page 31
Eth WAN-2 SFP.
For more information on the SFP interface, refer to:
- WAN connections on page 15
- WAN SFP connector on page 29
- WAN SFP interface on page 31
Aux. Provides access to the RS1800 series local console for configuration and
monitoring purposes.
For more information on the Aux connector, refer to:
- Connecting for configuration
- Configuration connector on page 30
- Configuration interface on page 35
SIM Card 1-2. Slot where you can insert the SIM cards for -4G models.
Refer to Installing the SIM card
tion.
On/Off switch.
Power source connection (PSU).
Refer to Power source on page 12 for more information on Power connection and
Power supply on page 36 for power specifications applicable to the RS1800
series device.
LED S (Status). Refer to LEDs
LED PWR (Power). Refer to
Functional earthing. Usually disconnected.
Cell connectors. Depend on model.
For more information on the Cellular interface, refer to:
- WWAN antenna connection (cell connector)
on page 18
on page 18 for more information on SIM installa-
on page 5 for more information.
LEDs on page 5 for more information.
on page 15
