Boot Mode Select Switch (Sw1) - Analog Devices ADSP-BF518F EZ-Board Manual

Push Button and Switch Settings

Boot Mode Select Switch (SW1)

The boot mode select switch (
cessor. Table 2-4
ADSP-BF518F processor boots from the on-board parallel flash memory.

The selected position of
entire rotating portion of the switch, not the small arrow.
Table 2-4. Boot Mode Select Switch (SW1)
SW1 Position
0
1
2
3
4
5
6
7
2-8
) determines the boot mode of the pro-
SW1
shows the available boot mode settings. By default, the
SW1
Processor Boot Mode
Idle – No Boot
Boot from 8- or 16-bit external flash memory (default)
Boot from internal SPI memory
Boot from external SPI memory (EEPROM or flash)
Boot from SPI0 host
Boot from OTP memory
Boot from SDRAM
Boot from host
UART0
ADSP-BF518F EZ-Board Evaluation System Manual
is marked by the notch down the
