Programmable Flags
Table 2-2. PG Port Programmable Flag Connections (Cont'd)
Processor Pin Other Processor Function
PG14 SPI0_MOSI/TMR1/PPIFS2_2/
PWM_TRIPB
PG15 SPI0_SSEL2/PPIFS3/AMS[3]
Table 2-3. PH Port Programmable Flag Connections
Processor Pin Other Processor Function
PH0 DR1PRI/SPI1_SS/RSI_DATA4
PH1 RFS1/SPI1_MISO/RSI_DATA5
PH2 RSCLK1/SPI1_SCK/RSI_DATA6
PH3 DT1PRI/SPI1_MOSI/RSI_DATA7
PH4 TFS1/AOE/SPI0_SSEL3/CUD
PH5 TSCLK1/ARDY/ECLK/CDG
PH6 DT1SEC/UART1_TX/
SPI1_SSEL1/CZM
PH7 DR1SEC/UART1_RX/TMR7/TACI2
2-6 ADSP-BF518F EZ-Board Evaluation System Manual
EZ-Board Function
Default:
SPI0_MOSI
Land grid array, expansion interface II
Default:
AMS3
, land grid array, expansion
SPI0_SEL2
interface II
EZ-Board Function
Default:
PB1
, , land grid array, expansion
DR1PRI MMC_D4
interface II
Default:
PB2
, , land grid array, expansion
RFS1 MMC_D5
interface II
Default: not used
, , land grid array, expansion
RSCLK1 MMC_D6
interface II
Default:
LED1
, ,
ADC_A0 MMC_D7 OTP_EN
sion interface II
Default:
CUD
SD card detect, land grid array, expansion
interface II
Default:
LED2
, , land grid array, expansion
CDG ADC_A1
interface II
Default:
LED3
, , land grid array, expansion
CZM ADC_A2
interface II
Default: not used
, land grid array, expansion interface II
DR1SEC
, land grid array, expan-
