Programmable Flags
Table 2-1. PF Port Programmable Flag Connections (Cont'd)
Processor Pin Other Processor Function
PF4 ERxCLK/PPID4/PWM_BL/TACLK1
PF5 ERxDV/PPID5/PWM_CH/TACI0
PF6 COL/PPID6/PWM_CL/TACI1
PF7 SPI0_SSEL1/PPID7/PWM_SYNC
PF8 MDC/PPID8/SPI1_SSEL4
PF9 RMIIMDIO/PPID9/TMR2
PF10 ETxD0/PPID10/TMR3
PF11 ERxD0/PPID11/PWM_AH/TACI3
PF12 ETxD1/PPID12/PWM_AL
PF13 ERxD1/PPID13/PWM_BH
PF14 ETxEN/PPID14/PWM_BL
PF15 RMII_PHYINT/PPID15/PWM_SYNC
2-4 ADSP-BF518F EZ-Board Evaluation System Manual
EZ-Board Function
Default:
ERXCLK
Land grid array, expansion interface II
Default:
ERXDV
Land grid array, expansion interface II
Default:
COL
Land grid array, expansion interface II
Default: not used
Land grid array, expansion interface II
Default:
MDC
Land grid array, expansion interface II
Default:
MDIO
Land grid array, expansion interface II
Default:
ETXD0
Land grid array, expansion interface II
Default:
ERXD0
Land grid array, expansion interface II
Default:
ETXD1
Land grid array, expansion interface II
Default:
ERXD1
Land grid array, expansion interface II
Default:
ETXEN
Land grid array, expansion interface II
Default:
RMII_PHYINT
Land grid array, expansion interface II
