Parallel Flash Memory Interface
information on how to initialize the registers after a reset, search the
online help for "reset values".
Parallel Flash Memory Interface
The parallel flash memory interface of the ADSP-BF518F EZ-Board con-
tains a 4 MB (2M x 16 bits) Numonyx M29W320EB chip. Flash memory
connects to the 16-bit data bus and address lines 1 through 19. Chip
enable is decoded by the
gates. The address range for flash memory is
Flash memory is pre-loaded with boot code for the power-on-self test
(POST) program. For more information, refer to
on page
1-28. Flash memory also is preloaded with configuration flash
information, which contains board revision, BOM revision, and other
data.
By default, the EZ-Board boots from the 16-bit parallel flash memory.
The processor boots from flash memory if the boot mode select switch
(
) is set to position 1 (see
SW1
page
2-8).
Flash memory code can be modified. For instructions, refer to the online
help and example program included in the EZ-Board installation
directory.
For more information about the parallel flash device, refer to the
Numonyx Web site:
eMMC Interface
The ADSP-BF518F processor is equipped with a removable storage inter-
face (RSI), which allows the 8 GB Micron eMMC flash memory device to
be attached gluelessly to the processor. The eMMC interface is attached
1-16
select lines through NAND and AND
AMS0—3
"Boot Mode Select Switch (SW1)" on
http://www.numonyx.com
ADSP-BF518F EZ-Board Evaluation System Manual
to
0x2000 0000
0x203F FFFF
"Power-On-Self Test"
.
.
