MII Connector (J15)

This connector is not populated on the board; it needs to be soldered on
to be used. This connector allows for mating with Ethernet evaluation
boards.
Part Description
40-position 0.50" TH receptacle

JTAG Connector (P1)

The JTAG header is the connecting point for the JTAG interface to the
ADSP-BF518F processor. The standalone debug agent requires both con-
nectors and
P1
Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When using an emulator with the EZ-Board, the standalone debug agent
must be removed. Follow the installation instructions provided in
Install and Session Startup" on page 1-5
sion Startup" on page
ADSP-BF518F EZ-Board Evaluation System Manual
ADSP-BF518F EZ-Board Hardware Reference
Manufacturer
TE Connectivity
.
ZP1
1-9, using
P1
Part Number
5787170-4F
or "VisualDSP++ Install and Ses-
as the JTAG connection point.
"CCES
2-23
