Connectors

Expansion Interface II Connectors (P2 and P4)

and are board-to-board connectors providing signals for the SPI,
P2 P4
TWI, UART, SPORT interfaces and GPIO signals of the processor. The
connectors are located on the upper and lower edges of the board. For
more information, see
ability and pricing of the connectors, contact Samtec.
Part Description
50-position 0.1", SMT header
50-position 0.1", SMT socket

Expansion Interface II Connector (P3)

is a board-to-board connector providing signals for the PPI, TWI, and
P3
GPIO signals of the processor. The connector is located on the upper edge
of the board. For more information, see
page 1-26. For availability and pricing of the connector, contact Samtec.
Part Description
70-position 0.1", SMT header
70-position 0.1", SMT socket
2-24
"Expansion Interface II" on page
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
SAMTEC
Mating Connector
SAMTEC
ADSP-BF518F EZ-Board Evaluation System Manual
1-26. For avail-
Part Number
TSSH-125-01-L-DV-A
SSW-125-22-F-D-VS
"Expansion Interface II" on
Part Number
TSSH-135-01-L-DV-A
SSW-135-22-F-D-VS
