Headset Function Select; One-Touch Ptt; Ptt Beep - Icom IC-705 Basic Manual

8
SET MODE
Bluetooth Set
» SET > Bluetooth Set

Headset Function Select

Selects the PTT and microphone combination
when both the Bluetooth headset and the
transceiver microphone are used.
• Normal: Transmits the audio from the Bluetooth
headset, or the transceiver microphone,
whichever [PTT] is pushed.
• Microphone:
Transmits the audio from the
Bluetooth headset. Transmission
is enabled by pushing either the
[PTT] on the Bluetooth headset, or
the transceiver microphone. The
transceiver microphone is only used
for the PTT control.
• PTT: Transmits the audio from
the transceiver microphone.
Transmission is enabled by pushing
either the [PTT] on the Bluetooth
headset, or the transceiver
microphone. The Bluetooth headset
is only used for the PTT control.
NOTE: DO NOT select "PTT" when the
microphone is not connected to the transceiver,
and you use only the Bluetooth headset.
LThe Bluetooth headset operation for each option is
listed below.
Option TX control
Normal Enabled
Microphone Enabled
PTT Enabled
» SET > Bluetooth Set > Headset Set
> Icom Headset
Power Save
Selects whether or not to operate with the
Power Save mode while the optional VS-3
headset is connected.
LWhen a headset (user supplied) or a data device is
connected, the Power Save mode is automatically
turned OFF, regardless of this setting.
• OFF: Turns OFF the function.
• ON: The Power Save mode is enabled
when no communication or operation is
performed for 120 seconds.
(Default: Normal)
TX audio
Enabled
Enabled
Disabled
( Audio from the microphone
is transmitted.)
(Default: OFF)

One-Touch PTT

Sets the One-Touch PTT function when the
optional VS-3 headset is connected.
This function enables you to transmit without
continuously holding down [PTT].
LWhen a headset (user supplied) is connected, this
function is automatically turned ON, regardless of
this setting.
• OFF: Transmits while holding down [PTT].
• ON: Pushing [PTT] toggles between transmit
and receive.

PTT Beep

Sets the beep sound when you push [PTT] on
the optional VS-3 headset.
• OFF: No beep sounds.
• ON: A beep sounds.
Custom Key Beep
Sets the beep sound when you push the
Custom Key ([PLAY]/[FWD]/[RWD]) on the
optional VS-3 headset.
• OFF: No beep sounds.
• ON: A beep sounds.
» SET > Bluetooth Set > Headset Set
> Icom Headset > Custom Key
[PLAY]
[FWD]
[RWD]
Assigns the functions to the Custom Key
([PLAY]/[FWD]/[RWD]) on the optional VS-3
headset.
LSee page 8-7 about the functions.
Mode Select
(Default:
Selects whether or not to enable to select
the mode by pushing the headset's key that
"MODE" is assigned.
LDisplays "✓" when the mode is selectable.
LThe settings are also used for the microphone.
When you change "Mode Select" in the "Function"
menu or the "Bluetooth Set" menu, the other is
automatically changed.
8-19
(Default: OFF)
(Default: OFF)
(Default: OFF)
(Default: Home CH)
(Default: UP (VFO: kHz))
(Default: DOWN (VFO: kHz))
SSB/ CW/ RTTY/
✔ ✔ ✔
AM/ FM/ DV/ WFM)
✔ ✔ ✔ ✔
