[NOTCH] Switch (SSB) (Default: Auto/Manual)
[NOTCH] Switch (AM)
Selects the Notch function used in the SSB or
AM mode.
• Auto: Only the Auto Notch function
can be used.
• Manual: Only the Manual Notch function
can be used.
• Auto/Manual: Both the Auto and Manual
Notch functions can be used.

SSB/CW Synchronous Tuning (Default: OFF)

Turns the Displayed Frequency Shift function
ON or OFF.
This function automatically shifts the frequency
to match the CW pitch when the operating
mode is toggled between SSB and CW.
• OFF: Turns OFF the function.
• ON: When the operating mode is changed
between SSB and CW, the operating
frequency shifts by the offset amount.

CW Normal Side

Selects the carrier point in the CW normal
mode.
• LSB: Sets the carrier point to the LSB side.
• USB: Sets the carrier point to the USB side.

Charging (Power ON)

Selects whether or not to charge the battery
pack when an external power source is
connected, even if the transceiver is ON.

USB Power Input (Phone, Tablet, PC)

Selects whether or not to use a mobile device or
a PC as an external power source.
Power OFF Setting (for Remote Control)
Selects whether or not to display the Standby/
Shutdown option dialog after holding down
for 1 second.
• Shutdown only: Shuts down the transceiver
when you turn it OFF.
• Standby/Shutdown:
Displays the Standby/
Shutdown option dialog when
you turn it OFF.
(Default: Auto/Manual)
(Default: LSB)
(Default: ON)
(Default: ON)
(Default: Shutdown only)
» SET > Function > Remote MIC Key
[A]
[B]
[]
[]
The function assignments for the [A], [B],
[], and [] keys on the HM-243 speaker
microphone can be changed.
LSee page 8-7 about the functions.
Mode Select
(Default:
Selects whether or not to enable to select the
mode by pushing the microphone's key that
"MODE" is assigned to.
LDisplays "✓" when the mode is selectable.
LThe settings are also used for the Bluetooth
headset. When you change "Mode Select" in the
"Function" menu or the "Bluetooth Set" menu, the
other is automatically changed.
» SET > Function
Keyboard Type
Sets the keyboard entry type to Ten-Key or Full
Keyboard.
Full Keyboard Layout
Sets the on-screen keyboard layout from
English, German, or French.
Screen Capture [POWER] Switch (Default: OFF)
Assigns the Screen Capture function to
• OFF: does not act as the Screen
Capture key.
• ON: acts as the Screen Capture key.
LWhen both "Screen Capture [POWER] Switch"
and "Screen OFF [POWER] Switch" are set to
ON, pushing
"Screen OFF" or "Screen Capture."
Screen Capture File Type
Sets the file format for the Screen Capture
function to PNG or BMP.
REF Adjust
Adjusts the internal reference frequency.
NOTE: The default setting of "REF Adjust" may
differ slightly, depending on the transceiver version.
8-6
SET MODE
(Default: Home CH)
(Default: VFO/MEMO)
(Default: UP (VFO: kHz))
(Default: DOWN (VFO: kHz))
SSB/ CW/ RTTY/
✔ ✔ ✔
AM/ FM/ DV/
✔ ✔ ✔ ✔
(Default: Full Keyboard)
(Default: English)
displays the dialog to select
(Default: PNG)
8
WFM)
8
.
