Subnet Mask (Valid After Restart); Default Gateway (Valid After Restart); Primary Dns Server (Valid After Restart); 2Nd Dns Server (Valid After Restart) - Icom IC-705 Basic Manual

8
SET MODE
WLAN Set
» SET > WLAN Set

Subnet Mask (Valid after Restart)

(Default: 255.255.255.0(24 bit))
Sets the subnet mask to connect to your PC or
Local Area Network (LAN), through your Router.

Default Gateway (Valid after Restart)

Sets the Default Gateway of the IC-705.
When you remotely control the IC-705 or
use the Internal Gateway function, a Default
Gateway setting is required.

Primary DNS Server (Valid after Restart)

Sets the Primary DNS Server address.

2nd DNS Server (Valid after Restart)

If there are two DNS server addresses, sets the
secondary DNS server address.
» SET > WLAN Set
Network Name
If you are operating the IC-705 using the
optional RS-BA1 or transferring a picture to the
IC-705 using the optional ST-4001W, enter a
network name of up to 15 characters.
» SET > WLAN Set > Remote Settings
Network Control (Valid after Restart)
Selects whether or not to remotely control the
IC-705.
• OFF: Disables remote control of the IC-705.
• ON: Enables remote control of the IC-705.
Control Port (UDP) (Valid after Restart)
Sets a port number for the control signal
transfers between the IC-705 and the remote
station, when you remotely control the IC-705.
Serial Port (UDP) (Valid after Restart)
Sets a port number for the serial data transfers
between the IC-705 and the remote station,
when you remotely control the IC-705.
Audio Port (UDP) (Valid after Restart)
Sets a port number for the audio signal transfers
between the IC-705 and the remote station,
(Default: . . . .)
when you remotely control the IC-705.
Internet Access Line (Valid after Restart)
Selects the Internet access line setting for the
IP remote control.
(Default: . . . .)
(Default: . . . .)
Network User1 ID
Network User2 ID
Sets a user name of up to 16 characters to use
when you remotely control the IC-705.
Network User1 Password
Network User2 Password
Sets a user password.
LThe password must include a minimum of 8
LYou cannot use a password that consists of
Network User1 Administrator
(Default: OFF)
Network User2 Administrator
Selects whether or not to set the user as an
administrator.
Only an authorized user can disconnect
communication between the IC-705 and the
remote station.
(Default: 50001)
Network Radio Name
Sets the IC-705's name of up to 16 characters
that is displayed in the remote control software,
when you remotely control the IC-705.
8-21
» SET > WLAN Set > Remote Settings
> Network User1
» SET > WLAN Set > Remote Settings
> Network User2
characters and a maximum of 16 characters.
exactly the same characters.
» SET > WLAN Set > Remote Settings
(Default: 50002)
(Default: 50003)
(Default: FTTH)
(Default: NO)
(Default: NO)
(Default: IC-705)
