3
BASIC OPERATION
Setting the frequency
D Directly entering a frequency (Continued)

Selecting a Memory channel by number

1. Select the Memory mode. (p. 3-1)
2. Select a memory group.
LTo select a memory group, touch the VFO/
MEMORY icon, and then touch [GROUP].
3. Touch the MHz digits. (Example: 14)
• Opens the BAND STACKING REGISTER
screen.
4. Touch [F-INP].
• Opens the F-INP screen.
5. Enter a Memory channel number. (Example: 2)
LIf the Call channel group is selected, enter
between "0" and "3."
0: 144 C1
1: 144 C2
2: 430 C1
3: 430 C2
6. Touch [MEMO] to set the memory channel of
the entered number.
• Closes the F-INP screen.
• The selected memory channel contents are
displayed.
DBand Edge Beep
You will hear a Band Edge Beep and
dotted line) will be displayed when you tune into
or out of an amateur band's frequency range.
LYou can change the Band Edge Beep settings in
the following menu.
» SET > Function > Band Edge Beep
LIf "Beep Level" is set to "0%," no beep sounds.
» SET > Function > Beep Level
DEntering a Band Edge
When "ON (User)" or "ON (User) & TX Limit" is
selected on the "Band Edge Beep" screen, you
can enter a total of 30 band edge frequency
pairs.
LInformation
• Initially, all Ham band frequencies are entered.
Therefore, you must first edit or delete them, and
then insert a new line to enter a new band edge.
• You cannot enter an overlapping frequency, or
a frequency that is out of the preset Ham band
frequencies.
• Band edges are entered from the lower frequency
first.
• These settings are easy with the CS-705. (p. 12-1)
1. Open the "Band Edge Beep" screen.
» SET > Function > Band Edge Beep
2. Touch "ON (User)" or "ON (User) & TX Limit."
LIf you set "ON (User) & TX Limit," you can limit
transmission to within the entered frequency
range.
3. Touch "User Band Edge."
• Opens the "User Band Edge" screen.
3-5
(with a
