The CLINITEK Status+ analyzer uses 6 AA-size batteries.
CAUTION
Do not use batteries in the analyzer, if you run a
CLINITEK Status+ analyzer with a CLINITEK Status connector.
Be sure to remove the batteries because they could leak and
damage the analyzer and the connector.
To change the batteries, perform the following steps:
1. Remove the test table by pulling it slowly out of the analyzer.
2. Drain the drip tray, if necessary.
3. Place the analyzer on its side.
4. Remove the battery cover on the bottom of the analyzer:
a. Press down on the tab.
b. Pull out the battery cover.
5. Replace the batteries:
a. Remove the current batteries.
b. Place 6 new AA-size batteries into the analyzer.
6. Insert the battery cover.
7. Turn the analyzer back onto its base.
8. Insert the test table and table insert.
