Settings
Name
Element
TriggerMode
Cycle
Deadband
Export collected values
By clicking Start export a dialog will appear. There all stored values can be selected to be
exported from the database to a comma separated file ".csv".
In the dialog the following parameters can be configured:
Line ending
Separator
Separate file for each element
Timestamp in seconds resolution
Select date range
Element list
Erase all entries in next startup
By selecting this option you can remove all entries from Data Logging in the next startup, this
option is reset afterwards.
Event Log Messages
The following section describes the messages that the Data Logging webservice may log to
the Event Log. All Messages are prefixed with the text Data Logging:.
• Online.
Data Logging is now online.
• Offline.
Data Logging is now offline.
• Restoring connection.
Data Logging is restoring connection.
• Waiting for database connection.
Data Logging is waiting for the database connection to be activated.
Anybus Edge Gateway Reference Guide
The element name is used as description of the corresponding database entry.
The value which will be stored in the database when this element is triggered. Multiple elements for
the same value are allowed.
Set the trigger mode with which values are stored to the database.
• cyclic
• deadband
Is used when the trigger mode is cyclic. After this many seconds the value will be stored in the database.
Is used when the trigger mode is deadband. A new value is only stored if the difference to the last
stored value is equal or larger than the deadband. If the deadband is again met before the value is
stored a message will be shown in the eventlog.
Not only the Elements of the current configuration are available to be exported, older
configurations and their values are retained until the Erase all entries in next
startup checkbox is set.
This paramater sets the line ending characters of the file.
• Windows - <CR><LF>
• Linux - <LF>
Separator that can be used to distinguish the values of the
file. If this option is left empty the semicolon will be used
as a separator.
For each element a separate export file will be created.
Timestamps are exported in econds resolution.
When this option is set only values in the date range are
exported.
A list with all the configured elements. Each element can
be select or deselected via its checkbox.
