Settings
• Error in receiving transmission acknowledgement packet for CODESYS Network Variable
packet with COB-ID <COB-ID>.
The driver requested an acknowledgement of its transmission from the receiving device but
has not received one during this cycle for this packet.
• Error sending variable in CODESYS Network Variable list with COB-ID <COB-ID>, variable
index <Sub-Index>. Error code: <Error-Code>.
There was an error during packet transmission. Please contact support.
• Variable with name: <Variable Name>, in list with COB-ID <COB-ID> (sub-index <Sub-
Index>) has an invalid or unsupported data type.
The data type of the named variable is not supported by the driver. Please look at the list
above for supported data types.
• Received CODESYS Network Variable acknowledgement packet with COB-ID <COB-ID>,
packet index <Packet-Index> with code Error code: <Error-Code>.
Received an acknowledgement that reports an error. To determine the error please refer to
CODESYS documentation or contact support.
• Portal communication error <error code>
A general error has occurred while exchanging data with the portal. Possible error codes:
-2
-3
If you see an error code that is not on the above list, please contact the customer support.
SNMP Manager
Your Edge gateway device features an SNMP Manager, which supports the protocol version
SNMPv2c. It can be configured through this form.
Agents and Values
At the top there is a list of SNMP agents and their values. You can add, edit, delete or clone
agents and values (input or output) via the buttons below the list. For each agent the list shows a
name, an IP address, a portal name, a community string and an index. For each value the list
shows a name, an OID, a portal name, a data type and an index. Most of these fields can be
edited (see below). The indexes are used internally to address the agents and their values.
When adding or editing a agent, a dialog will show up where you can configure the following
parameters:
Name
Portal Name
IP Address
Community
String
When adding or editing a value, another dialog will show up, the value will be added to the
currently selected group (Inputs or Outputs). Here you can configure the following parameters:
Name
Portal Name
OID
SNMP Data
Type
Anybus Edge Gateway Reference Guide
Out of memory
The internal data queue has overflown, because data was produced faster than it could be processed.
The agent's name.
A name used to build the path of the corresponding node on the portal.
The agent's IP address (e.g. 192.168.0.3).
Community String used for authentication with the agent.
The value's name.
A name used to build the path of the corresponding node on the portal.
Object ID used to address the value through the SNMP protocol.
The SNMP protocol data type:
Integer
