When using the FFS Wi-Fi transceiver, ensure port is configured for Traffic
Alert.
(6)
Configure at baud rate of 38400 when using Chelton FlightLogic display.
Ensure CSA bit is set per Section 3.5.4.13.3.2.
Setting
4800, 9600, 19200,
38400, 57600, 115200
230400, 460800

3.3.2.3 ARINC 429 Port Input Configuration

The ARINC 429 input data formats and speed configuration settings are described in the
following tables:
Table 9. ARINC 429 Port Input Configuration Settings
(1)
Setting
UNUSED
(Not Used)
ADC
(Air Data
Computer)
ADC&AHRS
(ADC+AHRS)
AHRS
(AHRS)
Transpndr-Cntrl
(Txpdr Control)
GPS-743
(GPS)
Traffic
(Other 1)
GPS-PRAIM-743
(Other 2)
3-18

Table 8. Serial Port Output Baud Rate Settings

These baud rates are typical for RS-232 or RS-422 equipment but
the correct rate must be selected to match the interfacing
equipment's configured or default baud rate.
These high baud rates are not normally recommended for RS-232
serial ports.
Interface
- No connection to ARINC 429 input port.
Altitude Input Altitude, Airspeed, Vertical Rate data input. Format for air
data sensors and computers that output the Air Data
Computer Labels listed in the table below.
Altitude & Altitude, Airspeed, Vertical Rate, & True Heading data
Heading input. Format for devices that output the Labels listed in
Input the ADC&AHRS table below.
Heading True Heading data input. Format for devices that output
Input the True Heading Label 314
Heading Squawk Code, IDENT, and Call Sign. Format for
Input transponders or controllers that output the ARINC
Transponder Control Data Labels listed in the table below.
GPS Input GPS position, velocity, time, and integrity data input.
Format for the FFS 1203 and 1203C or other sensors that
output the ARINC 743B labels (listed in GPS-743 Labels
Table below) and ALSO outputs a Time Mark that is UTC
second synchronized.
TCAS Input TCAS Intruder Traffic data input. Format for TCAS that
output the Labels listed in the Traffic Input table below.
GPS Input Accepts PRAIM input labels from FMS or other ARINC
743 devices.
Description
Description
