ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
5.3

TC978 Controller DO-160 Qualification

Temperature and Altitude
Ground Survival Low Temperature
Short-Time Operating Low Temperature
Operating Low Temperature
Short-Time Operating High Temperature
Ground Survival High Temperature
Operating High Temperature
Loss of Cooling
Altitude
Decompression
Overpressure
Temperature Variation
Humidity
Shock/Crash Safety
Vibration
Explosive Atmosphere
Waterproofness
Fluids Susceptibility
Sand and Dust
Fungus Resistance
Salt Fog
Magnetic Effect
Power Input
Voltage Spike
Audio Frequency Conducted Susceptibility –
Power Inputs
Induced Signal Susceptibility
Radio Frequency Susceptibility
Emission of Radio Frequency Energy
Lightning, Induced Transient Susceptibility
Lightning Direct Effects
Icing
Electrostatic Discharge
Fire, Flammability
5-2
Condition Para Category (DO-160F)
4 C4/C4/A4
4.5.1 -67°F [-55°C] (C4)
4.5.1 -13°F [-25°C] (C4)
4.5.2 -40ºF [-40°C] (C4)
4.5.3 +158ºF [+70°C] (C4)
4.5.3 +185°F [+85°C] (C4)
4.5.4 +131°F [+55°C] (C4)
4.5.5 N/A
4.6 +35,000ft (D)
4.6.2 +50,000ft (A)
4.6.3 -15,000ft (A)
5 A
6 A
7 B
8 U (Curve G)
9 N/A
10 W (front face only)
11 N/A
12 N/A
13 N/A
14 N/A
15 Z
16 N/A
17 N/A
18 N/A
19 BC
20 TT
21 M
22 XXJ3L3 (shielded)
XXH3L3 (unshielded)
23 N/A
24 N/A
25 N/A
26 C
