ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
The antenna lateral offset has the following options that can be selected:
1. Unknown
3. Left 2-4 meters
5. Central
7. Right 2-4 meters
The display screen is as shown below with one of the options from the list above.
Rotate the CODE knob either clockwise or counterclockwise to display the options above and
select the correct antenna offset. Once selected, press the ENT button to confirm selection and
move to the next configuration item in the setup mode.
Press ENT button and the display will instruct completion of setup and power off the system.

12.14 TC978 Test and Calibration

Refer to Section 3.7 - TC978 Test and Calibration.

12.15 Troubleshooting

Refer to SECTION 4 - Troubleshooting.

12.16 RTCA/DO-160 Environmental Qualifications

Refer to SECTION 5 - RTCA/DO-160 Environmental Qualifications.

12.17 Serial Interface Specifications

Refer to SECTION 6 - Serial Interface Specifications.

12.18 ADS-B Compliance

Refer to SECTION 7 - ADS-B Compliance.

12.19 Installation Drawings

Refer to SECTION 8 - Installation Drawings.
12-20
2. Left 0-2 meters
4. Left 4+ meters
6. Right 0-2 meters
8. Right 4+ meters
