data to the display as directional traffic. This parameter should only be set to "disable" for legacy
non-TSO-C195a displays without non-directional traffic symbols when occasional display of
non-directional traffic is deemed to be unacceptable or misleading. Otherwise leave this
parameter at the default setting of "enable."
The legacy MX-20 Display does not support non-directional traffic symbols and instead displays
a directional traffic symbol pointing at approximately 120 degrees from North. For compatibility
with the ADS-B system, the traffic velocity validation should be set to "enable" for this display.
3.5.4.13.3.4

"set displayout"

"trafficOnly" will provide traffic information to the display (position, ground track,
etc.) but no weather or other flight information.
"fisbOnly" will provide weather and flight information (NOTAMS, TFRs, ATIS,
etc.) but no traffic.
"traffic&fisb" will provide traffic, weather, and flight information simultaneously.
This command allows the installer to set the type of data to be sent to the display. The installer
can configure the FDL-978-XVR to output traffic only, FISB only, or both. By default, the FDL-
978-XVR will output the traffic and FISB data to the display.
