12.3 Parts and Equipment

12.3.1 FDL-978 Lite Series Items
The items included in the FDL-978-XVRL Ship Kit (P/N 87098-00-FX0L-KIT) are listed below:
Part Number
87098-00-FX0L
87349
86943-00
87875-00
The items included in the XVR Lite Installation Kit (P/N 87875-00) are listed below:
Part Number
85937
86966
81194
0129-0017-00
86945
85942
83145
87093
87094
84141
84192
84193
87872
87873
87866
FFS Copyright © 2015 All rights reserved.
Qty
1 FDL-978-XVRL Transceiver
1 TC978 Controller
1 FWF-125 Wi-Fi Transceiver
1 Kit, Installation, XVR Lite
Qty
1 Antenna UAT Ball & Stick TSO-C74c
1 BNC Connector Male RG-142 Crimp
1 Antenna GPS WAAS DO-228 TSO-C144
3 TNC Connector Male RG-142 Crimp
1 DB-44 Connector Male Crimp
1 DB-44 Connector Backshell
30 Pin Male 24-28 AWG Crimp
1 DB-15 Connector Female Crimp
1 DB-15 Connector Backshell
15 Socket Female 24-28 AWG Crimp
1 Connector, DB9F Crimp
1 Hood; 9 Pin Dsub
4 Screw 4-40 1.5 in MS Brass
4 Screw 4-40 0.625 in MS Brass
2 Bracket, Adapter, TC978, TC20
ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
Description
Description
