ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
The items included in the TC978 Installation Kit (P/N 86964) are listed below:
Item Qty
1 1 TC978 Mounting Adapter Bracket (circular hole adapter)
2 1 Hose EPDM Rubber 5 mm ID – 8 mm OD
3 1 Hose Connector 3/16 in Nylon Tee
4 2 Hose Adapter Straight Nylon 3/16 – 1/4 in
5 6 Constant Tension Clamp Application Dia 8.5 – 9 mm
6 2 Constant Tension Clamp Application Dia 9.5 – 10.3 mm
7 4 Screw, Brass Cross recessed Csk Head Black 4-40 UNC x 1.5 in Lg
8 4 Screw, Brass Cross recessed Csk Head Black 4-40 UNC x 0.625 in Lg
9 1 Connector Accessory Backshell, 9 Way D-Sub, 3 Way Entry, 4-40UN
Jackscrew
10 1 Connector Standard Mount 9 Way D receptacle to M24308
11 9 Crimp Socket Contact, Wire Size 20-24 AWG
The items included in the Personality Module Installation Kit (Male) (P/N 87002-00) are listed
below:
Part Number
85945-00-A
86967
83145
87006
The items included in the Personality Module Installation Kit (Female) (P/N 87002-10) are listed
below:
Part Number
85945-00-A
84141
87006
1-14
Description
Qty
1 Personality Module
6 Male Crimp Pin 24-28 AWG
6 Male Crimp Pin 24-28 AWG
1 Adhesive Double Sided Tape (0.5 in x 0.5 in)
Qty
1 Personality Module
6 Female Crimp Pin 24-28 AWG
1 Adhesive Double Sided Tape (0.5 in x 0.5 in)
Description
Description
