Table 13. Transpnder-Cntrl Input Arinc Labels - FreeFlight ADS-B FDL-978 Series Installation Manual

ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
Label
146
170
Label
016
031
233
234
235
236
Label 016 or 031 must be present as a minimum.
Labels 016 or 031 control only Squawk Code and IDENT.
Labels 233 – 236, if present, control Call Sign.
Label
203
210
212
Label
314
Table 16. ADC & AHRS Format Input ARINC Labels
Label
203
210
212
314
3-20
Description
PRAIM Satellite Deselect #1
PRAIM Satellite Deselect #2

Table 13. Transpnder-Cntrl Input ARINC Labels

TCAS/ATC Control (Squawk Code and IDENT only)
ATCRBS Control (Squawk Code and IDENT only)
Call Sign/Flight ID Characters 1&2
Call Sign/Flight ID Characters 3&4
Call Sign/Flight ID Characters 5&6
Call Sign/Flight ID Characters 7&8
Table 14. ADC Format Input ARINC Labels
Pressure Altitude
Airspeed
Altitude Rate
Table 15. AHRS Format Input ARINC Labels
True Heading
Pressure Altitude
Airspeed
Altitude Rate
True Heading
Description
Description
Description
Description
