Arinc 429 Port Input Configuration; Table 9. Serial Port Output - FreeFlight ADS-B FDL-978 Series Installation Manual

Setting
4800, 9600, 19200,
38400, 57600, 115200
230400, 460800

3.3.2.3 ARINC 429 Port Input Configuration

The ARINC 429 input data formats and speed configuration settings are described in the
following tables:
Table 10. ARINC 429 Port Input Configuration Settings
(1)
Setting
UNUSED
(Not Used)
ADC
(Air Data
Computer)
ADC&AHRS
(ADC+AHRS)
AHRS
(AHRS)
Transpndr-Cntrl
(Txpdr Control)
GPS-743
(GPS)
Traffic
(Other 1)
GPS-PRAIM-743
(Other 2)
(1)
Maintenance port setting names listed first with TC978 configuration menu
setting names in parenthesis ().
FFS Copyright © 2016 All rights reserved.
Table 9. Serial Port Output Baud Rate Settings
These baud rates are typical for RS-232 or RS-422 equipment but
the correct rate must be selected to match the interfacing
equipment's configured or default baud rate.
These high baud rates are not normally recommended for RS-232
Interface
-
Altitude Input Altitude, Airspeed, Vertical Rate data input. Format for air
data sensors and computers that output the Air Data
Altitude & Altitude, Airspeed, Vertical Rate, & True Heading data
Heading input. Format for devices that output the Labels listed in
Input
Heading True Heading data input. Format for devices that output
Input
Heading Squawk Code, IDENT, and Call Sign. Format for
Input transponders or controllers that output the ARINC
Transponder Control Data Labels listed in the table below.
GPS Input GPS position, velocity, time, and integrity data input.
Format for the FFS 1203C or other sensors that output the
ARINC 743A/B labels (listed in GPS-743 Labels Table
below) and ALSO outputs a Time Mark that is UTC
TCAS Input TCAS Intruder Traffic data input. Format for TCAS that
output the Labels listed in the Traffic Input table below.
GPS Input Accepts PRAIM input labels from the FMS or other ARINC
Lite Series Installation Manual
Document No. 87343 Rev G
Description
serial ports.
Description
No connection to ARINC 429 input port.
Computer Labels listed in the table below.
the ADC&AHRS table below.
the True Heading Label 314
second synchronized.
743A/B devices.
ADS-B FDL-978 Series and
3-13
