SECTION 7

ADS-B COMPLIANCE

ADS-B Parameters Supported:
#
1 ICAO 24-bit Address
2 Address Selection (ICAO vs Temporary)
3 Latitude
4 Longitude
Altitude Type Selection (Barometric vs
5
Geometric)
6 Barometric Pressure Altitude
7 Geometric Altitude
8 NIC
Automatic AIRBORNE/ON-GROUND
9
Indication
10 North Velocity
11 East Velocity
12 Ground Speed
13 Track Angle
14 Heading
15 Barometric Vertical Rate
16 Geometric Vertical Rate
17 A/V Length and Width, and POA
18 UTC 1 PPS Timing
19 Emitter Category
20 Call Sign
21 Emergency/Priority Status Selection
22 SIL
23 System Design Assurance (SDA)
24 SIL Supplement
25 NAC
P
26 NAC
V
27 NIC
BARO
FFS Copyright © 2015 All rights reserved.
Input Data Element
ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
Comment
(Use within the FDL-978-XVR)
Installation configuration
Anonymous discrete input
From GPS data
From GPS data
Baro unless invalid or inhibited
From altitude/air data sensor
From GPS data
From GPS data
Air/Ground discrete input
From GPS data
From GPS data
From GPS data
From GPS data
From configured heading input
From altitude/air data sensor
From GPS data
Installation configuration
From GPS Data
Installation configuration
From controller interface
From controller interface
GPS with HIL or HPL only
Installation configuration
GPS with HIL or HPL only
From GPS data
From GPS data
Non-Gilham altitude sensors only
7-1
