SECTION 5

RTCA/DO-160 Environmental Qualifications

U.S. standard units of measure are the primary means of identifying dimensions,
weights, etc. The equivalent metric values may also be shown in brackets (e.g.
1.9 in [48 mm]).
5.1 FDL-978 Equipment and UAT DO-160 Qualification
Temperature and Altitude
Operating Low Temperature
Operating High Temperature
Short-Time Operating Low Temperature
Short-Time Operating High Temperature
Ground Survival Low Temperature
Ground Survival High Temperature
Loss of Cooling
Altitude
Decompression
Overpressure
Temperature Variation
Humidity
Shock/Crash Safety
Vibration
Explosive Atmosphere
Waterproofness
Fluids Susceptibility
Sand and Dust
Fungus Resistance
Salt Fog
Magnetic Effect
Power Input
Voltage Spike
Audio Frequency Conducted Susceptibility –
Power Inputs
Induced Signal Susceptibility
Radio Frequency Susceptibility
Emission of Radio Frequency Energy
Lightning, Induced Transient Susceptibility
Lightning Direct Effects
Icing
Electrostatic Discharge
Fire, Flammability
FFS Copyright © 2015 All rights reserved.
Conditions
ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
Para Category (DO-160G)
C4 (-40ºF to +158ºF
4
[-40ºC to +70ºC])/D/A
4.5.2 -40ºF [-40°C] (C4)
4.5.4 +158ºF [+70°C] (C4)
4.5.1 -40ºF [-40°C] (C4)
4.5.3 +158ºF [+70°C] (C4)
4.5.1 -67°F [-55°C] (C4)
4.5.3 +185°F [+85°C] (C4)
4.5.5 N/A
4.6 +50,000ft (D)
4.6.2 +50,000ft (A)
4.6.3 -15,000ft (A)
5 B
6 A
7 B
8 S (Zone 1, Curve C) & U2
9 N/A
10 N/A
11 N/A
12 N/A
13 N/A
14 S
15 Z
16 BB
17 A
18 Z
19 AC
20 TT
21 B
22 A2J3L3 (shielded)
A2H3L3 (unshielded)
23 N/A
24 N/A
25 A
26 C
5-1
