ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F
The items included in the FDL-978-TXL Ship Kit (P/N 87098-00-FT0L-KIT) are listed below:
Part Number
87098-00-FT0L
87349
87874-00
The items included in the TX Lite Installation Kit (P/N 87874-00) are listed below:
Part Number
85937
86966
81194
0129-0017-00
86945
85942
83145
84141
84192
84193
87872
87873
87866
12-6
Qty
1
FDL-978-TXL Transmitter
1
TC978 Controller
1
Kit, Installation, TX Lite
Qty
1
Antenna UAT Ball & Stick TSO-C74c
1
BNC Connector Male RG-142 Crimp
1
Antenna GPS WAAS DO-228 TSO-C144
3
TNC Connector Male RG-142 Crimp
1
DB-44 Connector Male Crimp
1
DB-44 Connector Backshell
30
Pin Male 24-28 AWG Crimp
9
Socket Female 24-28 AWG Crimp
1
Connector, DB9F Crimp
1
Hood; 9 Pin Dsub
4
Screw 4-40 1.5 in MS Brass
4
Screw 4-40 0.625 in MS Brass
2
Bracket, Adapter, TC978, TC20
Description
Description
FFS Copyright © 2015 All rights reserved.
