ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev F

12.12 Installation Setup and Configuration

12.12.1 FDL-978 Lite Series Configuration Item Summary
Configuration Item
Altitude Encoder (Port 4)
Configuration:
Configuration Item
ICAO Address (Mode S)
Call Sign/Flight ID
Emitter (Aircraft) Category
Squat Mode
Groundspeed Threshold
Aircraft Size:
GPS Antenna Offset:
VFR Squawk Code
VFR Squawk Code is only set on the TC978.
(1)
12.12.2 FDL-978 Lite Series Interface Configuration Details
12.12.2.1

Control Data Interface

FAA AC 20-165A HIGHLY recommends that the ADS-B transmitter and
transponder share a single point of entry for Mode A (Squawk Code) and IDENT.
Dual entry installations are allowed but discouraged and must ensure that the
transponder and UAT transmit the same Mode A and IDENT without increased
pilot workload. Garmin Series transponders (GTX-330/327/32/33) must be
connected to the GTX-REMOTE Input port on the FDL-978 Lite Series to control
Mode A code and IDENT. Mode A/C transponders will automatically use the
FDL-978 Lite Series internal Mode A receiver to monitor the on-board
transponder transmissions to set Mode A code and IDENT. Mode A receive is
not compatible with Mode S transponders.
12-12

Table 22. Serial Port Configuration Settings

IN Function
Baud
Table 23. ADS-B Transmit Configuration Settings
Length
Width
Longitudinal
Lateral
(1)
Default
UNUSED
9600
Default
0
UNKNOWN
None
0 knots
0
0
No Data
No Data
1200
FFS Copyright © 2015 All rights reserved.
