SECTION 7

ADS-B COMPLIANCE

ADS-B Parameters Supported:
#
1
2 Address Selection (ICAO vs Temporary)
3
4
Altitude Type Selection (Barometric vs
5
6 Barometric Pressure Altitude
7
8
Automatic AIRBORNE/ON-GROUND
9
10
11
12
13
14
15
16
17 A/V Length and Width, and POA
18
19
20
21 Emergency/Priority Status Selection
22
23 System Design Assurance (SDA)
24
25
26
27
28
FFS Copyright © 2016 All rights reserved.
Input Data Element
ICAO 24-bit Address
Latitude
Longitude
Geometric)
Geometric Altitude
NIC
Indication
North Velocity
East Velocity
Ground Speed
Track Angle
Heading
Barometric Vertical Rate
Geometric Vertical Rate
UTC 1 PPS Timing
Emitter Category
Call Sign
SIL
SIL Supplement
NAC
P
NAC
V
NIC
BARO
Capability Codes
ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev G
Comment
(Use within the FDL-978-XVR)
Installation configuration
Anonymous discrete input
From GPS data
From GPS data
Baro unless invalid or inhibited
From altitude/air data sensor
From GPS data
From GPS data
Air/Ground discrete input
From GPS data
From GPS data
From GPS data
From GPS data
From configured heading input
From altitude/air data sensor
From GPS data
Installation configuration
From GPS Data
Installation configuration
From controller interface
From controller interface
GPS with HIL or HPL only
Installation configuration
GPS with HIL or HPL only
From GPS data
From GPS data
Non-Gilham altitude sensors only
Installation configuration
7-1
