Introduction; Preparing For Installation - Raven SmarTrax Installation Manual

Macdon m150, m155, m200, and m205 series windrower

Hide thumbs Also See for SmarTrax:

Table of Contents

CHAPTER

Congratulations on your purchase of the SmarTrax system! This system is designed to provide cutting-edge,

hands-free steering of the machine via Global Positioning System (GPS) coordinates.

This manual applies to the following machines:

MAKE: MacDon Windrower

MODEL: M150, M155, M200, and M205

MacDon M205

FIGURE 1.

Important:

Install the MacDon AutoSteer hydraulic interface kit (MacDon P/N B5589) on the machine before

installing the SmarTrax system. Contact your local MacDon dealer for ordering information.

Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the

machine and leave it turned off for the duration of the installation process.

During the installation process, follow good safety practices. Be sure to carefully read the instructions in this

manual as you complete the installation process.

Manual No. 016-5030-009 Rev. B

I ntroduction

C h a p t e r 2

Table of Contents

Need help?

Do you have a question about the SmarTrax and is the answer not in the manual?
