Kit Contents

This section contains a list of the components that are included in the SmarTrax kit. Before beginning the
SmarTrax installation, compare the items in the kit with the components on this list. If you have questions about
the kit, contact your Raven dealer.
SmarTrax Installation Kit (P/N 117-5030-009)
TABLE 1.
Not Pictured
Not Pictured
Manual No. 016-5030-009 Rev. B
techwriting@ravenind.com
Item Description
Manual - MacDon M-Series Windrower
SmarTrax Installation
Manual - SmarTrax and SmartSteer
Calibration & Operation
Node - SmarTrax 3D CAN Control
Bracket - Node Mounting
Introduction
Part Number Qty.
016-5030-009
016-0171-277
063-0173-484
107-0172-055
1
1
1
1
5
