Mounting Instructions

If desired, rack mount the switcher as follows:
1.
2.

Battery and Power Precautions

The matrix switcher is provided with a permanently installed (factory-soldered in place)
lithium battery. The battery maintains the real time clock in the event of power failure or
extended storage periods and does not affect the normal operation of the switcher. If the
battery becomes ineffective, return the switcher to Extron for repair.
AVERTISSEMENT : Si la pile est mal remplacée, il y a un risque d'explosion. N'essayez

Removing and Installing an I/O Module

NOTE: All the diagrams in the section show the 40x frame, which is similar in function to
AVERTISSEMENT : Les cartes d'E/S fibre optique FOX3 émettent une lumière invisible
NOTES:
Insert the unit into the rack, aligning the mounting bracket holes with those in the rack.
Secure the switcher to the rack using the supplied bolts.
WARNING: There is a danger of explosion if the battery is incorrectly replaced. Do
not attempt to remove or replace the internal battery.
pas de retirer ou de remplacer la batterie interne.
the 80x frame.
WARNING: The FOX3 matrix switchers fiber optic I/O boards output continuous
invisible light (Class 1 rated), which may be harmful to the eyes; use with caution.
Do not look into the fiber optic cable connectors or into the fiber optic cables
themselves. Plug the attached dust cap into the optical transceiver when the fiber
optic cable is unplugged.
continue, qui peut être dangereuse pour les yeux ; à utiliser avec précaution.
Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
ou dans les câbles fibre optique eux-mêmes. Branchez la protection contre la
poussière dans l'ensemble émetteur/récepteur lorsque le câble fibre optique est
débranché.
• As factory configured, the fiber optic I/O boards are either 100 percent singlemode
or 100 percent multimode, but a fiber optic transceiver module (one input and one
output) of one transmission mode can be removed and replaced with a block of the
other transmission mode.
Transmission mode transceiver modules can be mixed on a fiber optic I/O board,
provided each fiber cable and connected devices are the appropriate transmission
mode for the transceiver module. Typically, singlemode fiber has a yellow jacket and
multimode cable has an orange or aqua jacket.
• For proper cooling and air flow, boards or blank panels should be installed in all
locations during normal switcher operations.
