Operation instructions
2.

Technical data

Type of duty:
Limit switching:
Torque switching:
Operating time:
Heater in switch compartment:
Motors:
Motor protection:
Electrical connection:
Wiring diagram:
Ambient temperature:
Enclosure protection:
Finish coating:
Technical data
Torque for Tripping
1)
modulating torque
both
directions
max. min. max.
Nm Nm Nm
15 15
30
30 30
60
30 30
60
60 60
120
Electrical data
Torque for Tripping
1)
torque
modulating
both
directions
max. min. max.
Nm Nm Nm
15 15
30
30 30
60
30 30
60
60 60
120
1) adjustable
2) with 40% ED, for nominal voltage and
20 °C ambient temperature
Intermittent duty S5 - 40 % ED - 1500 c/h (according to VDE 0530)
Counter gear mechanism for end positions CLOSED / OPEN
Adjustable torque switching for closing and opening direction
Output speed adjustable via controls AUMA VARIOMATIC
5 - 20 W, 110 V - 250 V or 24 - 48 V, external supply.
Electronically commutated special AUMA motor.
Thermistor motor protection.
Standard: AUMA plug/socket connector 100 with screw cable terminations.
Refer to name plate.
− 25 °C to + 60 °C
Standard: IP 67 according to EN 60 529
Standard: two-component iron-mica combination
Valve Stem AUMA
mounting diameter modulating actuator
flange type
Standard
ISO 5210
(Special max.
DIN 3210) mm
F 07
SARV 07.1-...3/32
F 10
26
(G 0)
SARV 07.1-...4/45
F 07
SARV 07.5-...3/32
F 10
26
(G 0)
SARV 07.5-...4/45
SARV 10.0-...3/32
F 10
40
(G 0)
SARV 10.0-...4/45
SARV 10.1-...1,5/16
F 10
40
(G 0)
SARV 10.1-...2/22
Valve Stem AUMA
mounting diameter modulating actuator
flange type
Standard
ISO 5210
(Special max.
DIN 3210) mm
F 07
SARV 07. 1-...3/32
F 10
26
(G 0)
SARV 07. 1-...4/45
F 07
SARV 07.5-...3/32
F 10
26
(G 0)
SARV 07.5-...4/45
SARV 10.0-...3/32
F 10
40
(G 0)
SARV 10.0-...4/45
SARV 10.1-...1,5/16
F 10
40
(G 0)
SARV 10.1-...2/22
3) for identical direction of rotation
4) with motor, output drive B 1 and
controls AUMA VARIOMATIC
Multi-turn actuators SARV 07.1 - SARV 10.1
1-phase AC (standard voltages and frequencies)
V
Hz
Number Minimum
of duration
2)
starts of im-
pulse
speed
min/max max.
1/min c/h ms
1500 50
1500 50
1500 50
1500 50
Motor type
speed
min/max
1/min
VEC 56-12-32-R
VEC 56-12-32-R
VEC 56-12-32-R
VEC 56-12-32-R
Recommended fuses in mains: 16 A.
AUMA VARIOMATIC
220 - 240
50
Back Handwheel Hand-
lash diameter wheel
reduc-
3)
tion
min.
ms mm
75 160
75 160
75 200
75 200
Electr. power Current at
consumption max. speed and
at max. max. torque
5)
torque
approx. W
500
600
700
900
700
900
700
900
5) motor and controls
220 - 240
60
4)
Weight
kg
(approx.)
8:1
23
4:1
8:1
23
4:1
8:1
27
4:1
8:1
27
4:1
220 - 240 V
50 / 60 Hz
max. A
4
5
6
7
6
7
6
7
5
