13. Setting of the electronic position transmitter RWG (option)

Figure M
The electronic position transmitter is set in our factory according to the sig-
nal range stated in the order. Perform a subsequent adjustment according
to subclause 13.1 or 13.2.
After mounting the multi-turn actuator on the valve check setting and adjust,
if necessary.
Technical
data
Output I
Supply
U
voltage
max. current drawn I
max. ext. resistance R
Figure N: Positioner board
1 2 3 4
3- and 4- wire system
2- wire system
For change-over also change wiring
Multi-turn actuators SARV 07.1 - SARV 10.1
RWG 4020
3-/4- wire system
0 - 20 mA, 4 - 20 mA
24 V DC, ±15%
v
smoothed
24 mA at 20 mA
output current
600 Ω
B
max
(0/4 mA)
(20 mA)
N R2 M
Measuring
Measuring-
point 1 point 2
+
0/4 - 20 mA
AUMA VARIOMATIC
Cover plate
R2
2-wire system
4 - 20 mA
14 V DC + (I x R ),
B
max. 30 V
20 mA
(Uv - 14 V) / 20 mA
5 6 7
-
15
