8.6.4

Interface

Find CN10 (Left) pin-out in
Pin
number
1
3
5
7
9
11
13
15
17
19
UM2662 - Rev 1
Figure 32. MB1242 OCSPI module connectors CN10 and CN11
Table 57.
Table 57.
Description Pin connection
OCSPI2_NCS
OCSPI2_IO0
OCSPI2_IO1
OCSPI2_IO2
OCSPI2_IO3
OCSPI2_DQS
GND
OCSPI2_CLK_N
OCSPI2_CLK_P
GND
CN10 (Left) MB1242 pin-out
Pin
number
PG12 2
PF0 4
PF1 6
PF2 8
PF3 10
PG15 12
GND 14
PF5 16 OCSPI2_RESET
PF4 18
GND 20
UM2662
OCSPI NOR Flash 2 module (MB1242)
Description Pin connection
3V3_AO 3V3_AO
3V3_AO 3V3_AO
OCSPI1_NCS PG6
OCSPI2_IO4 PG0
OCSPI2_IO5 PG1
OCSPI2_IO6 PG10
OCSPI2_IO7 PG11
NRST
GND GND
GND GND
page 60/95
