ST STM32H7B3I-EVAL User Manual page 75

LQFP144 pinout
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
UM2662 - Rev 1
Main function pinout
Pin name
assignment
VDD_SMPS POWER
VLX POWER
VSS_SMPS POWER
VSS POWER
V15 POWER
VDD POWER
PB13 RS-232 LPUART1_CTS
PB14 UCPD_DB2
PB15 UCPD_CC2
PD8 LCD-SRAM-FMC_D13
PD9 LCD-SRAM-FMC_D14
PD10 LCD-SRAM-FMC_D15
PD11 SRAM-FMC_A16
PD12 SRAM-FMC_A17
PD13 SRAM-FMC_A18
VSS POWER
VDD POWER
PD14 LCD-SRAM-FMC_D0
PD15 LCD-SRAM-FMC_D1
PG2 SRAM-FMC_A12
PG3 SRAM-FMC_A13
PG4 SRAM-FMC_A14
PG5 SRAM-FMC_A15
PG6 RS-232 LPUART1_RTS
PG7 RS-232 LPUART1_TX
PG8 RS-232 LPUART1_RX
VSS POWER
VDD POWER
PC6 -
PC7 DFSDM1_DATIN3
PC8 SDIO1_D0
PC9 SDIO1_D1
PA8 Smartcard USART1_CK
PA9 Smartcard USART1_TX
STM32H7B3I-EVAL I/O Assignment
Optional function pinout
Motor-control connector
assignment
-
-
-
-
-
-
STMOD+_LPUART1_CTS
PMOD_LPUART1_CTS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
STMOD+_LPUART1_RTS
PMOD_LPUART1_RTS
STMOD+_LPUART1_TX
PMOD_LPUART1_TX
VCP_LPUART1_TX
STMOD+_LPUART1_RX
PMOD_LPUART1_RX
VCP_LPUART1_RX
-
-
Touch key
Touch key
-
TRACE_D0
-
-
UM2662
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
TIM8_CH1
TIM8_CH2
TIM8_CH3
-
-
TIM1_CH2
page 75/95
