Conventions
Table 3
provides the conventions used for the ON and OFF settings in the present document.
Convention
Jumper JPx ON
Jumper JPx OFF
Jumper JPx [1-2]
Solder bridge SBx ON
Solder bridge SBx OFF
Resistor Rx ON
Resistor Rx OFF
UM2662 - Rev 1
Table 3.
ON/OFF convention
Jumper fitted
Jumper not fitted
Jumper should be fitted between Pin 1 and Pin 2
SBx connections closed by 0 Ω resistor
SBx connections left open
Resistor soldered
Resistor not soldered
Definition
UM2662
Conventions
page 5/95
