8.3

GenICam Image Format Control

Name
SensorWidth
SensorHeight
MaxWidth
MaxHeight
Width
Height
OffsetX
OffsetY
ReverseX
PixelFormat
PixelCoding
PixelSize
PixelColorFilter
TestImageSelector
VideoMode
PixelBigEndian
BinningHorizontal
BinningVertical
PixelDynamicRangeMin
PixelDynamicRangeMax
2/10/2017
©2013-2017
FLIR Integrated Imaging
Solutions Inc. All rights reserved.
Display
Name
Sensor Width Effective width of the sensor in pixels
Sensor Height Effective height of the sensor in pixels
Max Width Maximum width of the image in pixels
Max Height Maximum height of the image in pixels
Width Width of the image provided by the device in pixels
Height Height of the image provided by the device in pixels
Offset X Vertical offset from the origin to the AOI in pixels
Offset Y Horizontal offset from the origin to the AOI in pixels
Flip horizontally the image sent by the device. The AOI
Reverse X
is applied after the flip
On Board Color Enable FPGA processing (i.e., Gamma/Lookup table).
Process Enabled This limits frame rate.
Format of the pixel data (not all cameras support all
Pixel Format
formats)
Pixel Coding Coding of the pixels in the image
Pixel Size Size of a pixel in bits
Pixel Color Filter Type of color filter that is applied to the image
Test Image Selects the type of test image that is sent by the
Selector camera
Video Mode Current video mode
Pixel BigEndian Set the pixel endianess for pixel format Mono16
Binning
Number of horizontal pixels to combine together
Horizontal
Binning Vertical Number of vertical pixels to combine together
Dynamic Range Indicates the minimum pixel value transferred from the
Min camera
Dynamic Range Indicates the maximum pixel value transferred from
Max the camera
®
Grasshopper 3 PGE Technical Reference
8 Grasshopper3 PGE Attributes
Description Value
True
False
True
False
Mono8,
Mono12,
Mono16,
Raw8,
Raw12,
Raw16,
RGB,
YUV411,
YUV422
Mono
Raw
YUV
RGB
8/12/16/24
Off
Test Image
1
Test Image
2
0 ... 8
True
False
