Configuring VME Option Boards
VTC
The jumper configuration shown on the
right is for board position 0 and for
DG/UX revision 5.4.2 or later. To
configure for other board positions or
other revisions of the operating system,
refer to the tables that follow.
Figure 2–6 VTC Board Jumper Locations
2-18
E5
2 1
E4
E14
1
2
2 1
E5
E3
E4
E14
E3
2 1
014–001867
