Model 7411–KA
Junction Box
These instructions outline how to mount a J-box to an office wall; you can adapt
these procedures to suit your particular environment. As described, the installation
requires the following tools and equipment:
Appropriate anchors and screws to secure the assembly to a wall or other
mounting surface; the devices below work on most surfaces.
Toggle bolt—
for wall paneling
and wallboard
Medium (#2) Phillips screwdriver.
Flat-blade screwdriver.
Pencil.
Punch, or hammer and large nail.
Tape or paper clip (for Model 7411–K assembly only).
014–001867
Special Instructions for Model-Specific VME Hardware
Asynchronous
device connectors
Cable connector
5-ft cable
to rear of computer
Figure D–12 VAC/16 Junction Boxes
Expanding insert—
for wall paneling and
wallboard
Cable connector
Cable tension bar
Model 7411–K
Junction Box
Vinyl insert—
for masonry
D-11
