Pin Row A
1 D00
2 D01
3 D02
4 D03
5 D04
6 D05
7 D06
8 D07
9 GND
10 SYSCLK
11 GND
12 DS1
13 DS0
14 WRITE
15 GND
16 DTACK
17 GND
18 AS
19 GND
20 IACK
21 IACKIN
22 IACKOUT
23 AM4
24 A07
25 A06
26 A05
27 A04
28 A03
29 A02
30 A01
31 –12 V
32 +5 V
014–001867
VME Backplane Connector Signals and Power Distribution
Table A–1 Connector J1 Signals
Row B
BBSY
BCLR
ACFAIL
BG0IN
BG0OUT
BG1IN
BG1OUT
BG2IN
BG2OUT
BG3IN
BG3OUT
BR0
BR1
BR2
BR3
AM0
AM1
AM2
AM3
GND
Reserved
Reserved
GND
IRQ7
IRQ6
IRQ5
IRQ4
IRQ3
IRQ2
IRQ1
+5 V STBY
+5 V
Row C
D08
D09
D10
D11
D12
D13
D14
D15
GND
SYSFAIL
BERR
SYSRESET
LWORD
AM5
A23
A22
A21
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A09
A08
+12 V
+5 V
A-3
