Special Instructions for Model-Specific VME Hardware
Figure D–1 illustrates how to replace securing screws on an option board air dam.
Plastic stand-off
É É É
É É É
Captive screw
Air dam
É É É
É É É
Removing stand-off
and screw
Figure D–1 Removing Screws and Stand-offs from Air Dam
Once you have secured the board(s) in the card cage, return to Chapter 3 and
continue with the last section, "Completing the Configuration."
D-2
Stand-off
and captive screw
installed
É
Stand-off
and captive screw
removed
Replacement screw
É
Securing bars
Computer chassis — side view
014–001867
(internal)
