Board Slot Maps, Power
Requirement Forms, and Device
Line Worksheets
Use the form(s) in this appendix to perform the following tasks:
Record the location of the boards in your system.
Note whether slot 1 in the VME card cage requires jumpers on the backplane.
(Slot 1 requires backplane jumpers only if slot 2 contains a VME board and slot 1
remains empty.)
Calculate the current and power requirements of your computer's configuration.
Record the connections of asynchronous devices to VAC/16 junction boxes and
VDA cluster boxes.
Refer to Chapter 1 for additional information on board slot maps and power
requirement forms. Refer to Chapter 4 for additional information on device line
worksheets.
The examples in Figure B–1 show possible AViiON configurations. Use the
diagrams that follow for your configurations.
014–001867
Appendix B
B-1
