Vac/16 Board Jumper Locations - Data General AViiON Series Customer Documentation

NOTE: Verify that the VME controller you plan to install is jumpered
appropriately for the current revision of your DG/UX operating system.
Once you have installed the board jumpers and verified the switch settings, follow
the special instructions in Chapter 4 that describe connecting the VAC/16 controller
to its junction box (J-box) assembly. After you connect the board and J-box(es),
follow the instructions in Chapter 3 to install the VAC/16 board into the card cage.
VAC16
E15
The E1, E2, and E15 jumper configuration
shown above is for board position 0 and for
DG/UX revision 5.4.2 or later. To configure
for other board positions, refer to the tables
that follow.
E15
Figure 2–3 VAC/16 Board Jumper Locations
014–001867
E1
SW1
8
1
ON 1
E1 E2
SW1
Configuring VME Option Boards
1
E2
1
2-5
