This section provides users with detailed descriptions in terms of how to set up basic
system configurations through the BIOS setup utility.

4.1 Starting

To enter the setup screens, follow the steps below:
1. Turn on the computer and press the <Del> key immediately.
2. After press the <Del> key, the main BIOS setup menu displays.
other setup screens, such as the Advanced and Chipset menus, from the main BIOS
setup menu.
It is strongly recommended that
and system manufacturer have carefully set up these defaults that provide the best
performance and reliability.

4.2 Navigation Keys

The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS
setup utility hot keys can be used at any time during the setup navigation process. These keys
include <F1>, <F2>, <Enter>, <ESC>, <Arrow> keys, and so on.
【Note】:
Some of the navigation keys differ from one screen to another.
Hot Keys
 Left/Right
 Up/Down
+ Plus/Minus
Tab
F1
F2
F3
F4
Esc
Enter
BIOS Setup Utility
should avoid changing the chipset's defaults. Both AMI
users
Descriptions
The Left and Right <Arrow> keys allow users to select a setup
screen.
The Up and Down <Arrow> keys allow users to select a setup screen
or sub-screen.
The Plus and Minus <Arrow> keys allow users to change the field
value of a particular setup item.
The <Tab> key allows users to select setup fields.
The <F1> key allows users to display the General Help screen.
The <F2> key allows users to Load Previous Values.
The <F3> key allows users to Load Optimized Defaults.
The <F4> key allows users to save any changes they made and exit
the Setup. Press the <F4> key to save any changes.
The <Esc> key allows users to discard any changes they made and
exit the Setup. Press the <Esc> key to exit the setup without saving
any changes.
The <Enter> key allows users to display or change the setup option
listed for a particular setup item. The <Enter> key can also allow
users to display the setup sub- screens.
eBOX100-312-FL Series user's Manual
SECTION 4
BIOS SETUP UTILITY
Users
can access to
31
