  • Page 1 Series Embedded System User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permissions of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The eBOX630-528-FL does not come with an operating system which must be loaded first before installation of any software into the computer. Be sure to ground yourself to prevent static charge when installing any internal components.

  • Page 4: Classifications

    Classifications Degree of production against electric shock: not classified Degree of protection against ingress of water: IP40 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Mode of operation: Continuous...

  • Page 5: General Cleaning Tips

    General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner to absorb dirt on the floor.

  • Page 6: Scrap Computer Recycling

    Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Precautions ....................iii Classifications ....................... iv General Cleaning Tips ................... v Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION................. 1 General Descriptions ................. 1 System Specifications ............... 3 1.2.1 CPU ........................3 1.2.2 I/O System ......................
  • Page 8 3.3.16 Full-Size PCI Express Mini Card Slot (CN6,CN7) ........33 SECTION 4 BIOS SETUP UTILITY .............. 35 Starting ..................... 35 Navigation Keys ................35 Main Menu ..................36 Advanced Menu ................37 Chipset Menu ................... 54 Boot Menu ..................59 Save &...

  • Page 9: Section 1 Introduction

    Core™ i7/i5/i3 & Celeron ® ® The eBOX630-528-FL Series features 8th Gen Intel processors (Whiskey Lake), high performance yet low power consumption, fanless slim type design, -40°C to +70°C extended operating temperature*, and 9V to 36V wide range DC power input with industrial-grade reliability. Highly integrated and with rich IO configuration, the eBOX630-528 is perfectly suitable for factory automation or any AIoT/Industry 4.0...
  • Page 10 Series User’s Manual Reliable and Stable Design Core™i7-8665UE/i5-8365UE/i3- ® The embedded system supports 8th generation Intel ® 8145UE & Celeron 4305UE processors, along with the features of high performance, industrial-grade operation temperature/power input and multi-functional design that make it the best solution for smart factory/factory automation applications.

  • Page 11: System Specifications

    Series User’s Manual 1.2 System Specifications 1.2.1 CPU ⚫ Core™ i7-8665UE Processor ® ◼ Intel Core™ i5-8365UE Processor ® ◼ Intel Core™ i3-8145UE Processor ◼ ® Intel ® ® ◼ Intel Celeron 4305UE Processor ⚫ Chipset ◼ ⚫ BIOS ◼...

  • Page 12: System Specifications

    Series User’s Manual ⚫ Mini PCIe Interface ◼ 2 x full-size PCI Express Mini Card slots -Slot A (USB + PCIe signal) -Slot B (USB + PCIe + SATA signal) ⚫ Storage ◼ 2 x 2.5" swappable SATA HDD/SSD drive bays, up to 9.5mm in height (Software RAID 0,1) ◼...

  • Page 13: Driver Cd Contents

    3.0 kg (6.6 lb) with package ⚫ Dimension ◼ 250mm (9.84") (W) x 170mm (6.69") (D) x 60mm (2.36") (H) 1.2.4 Driver CD Contents Please download the following eBOX630-528-FL drivers from the Axiomtek official website. ⚫ Ethernet ⚫ Chipset ⚫...

  • Page 14: Dimensions

    Series User’s Manual 1.3 Dimensions The following diagrams show dimensions and outlines of the eBOX630-528-FL. 1.3.1 System Dimensions Introduction...

  • Page 15: Wall-Mount Bracket Dimensions

    Series User’s Manual 1.3.2 Wall-mount Bracket Dimensions From the accessories box, users can get 4pcs of truss head M3*6L screws for fixing the wall mount kit. Note: When users install the wall mount kit, please turn the LAN ports side outlet towards the floor.
  • Page 16 Series User’s Manual Wall-mount Bracket Assembly Drawing From the accessories box, users can get 4pcs of truss head M3*6L screws for fixing the wall mount kit. Note : If users install the screws in drywall, use the hollow wall anchors to ensure that the unit does not pull away from the wall due to prolonged strain between the cable and the power connector.

  • Page 17: Din-Rail Bracket Dimensions

    Series User’s Manual 1.3.3 DIN-Rail Bracket Dimensions From the accessories box, users can get 4pcs of truss head M3*6L and 6pcs of M3*4L countersunk flat head screws for fixing the DIN-rail mount kit. Introduction...
  • Page 18 Series User’s Manual DIN-Rail Bracket Assembly Drawing From the accessory box, users can get 6pcs of truss head M3*6L screws for fixing the wall mount kit. Introduction...

  • Page 19: I/O Outlets

    Series User’s Manual 1.4 I/O Outlets The following figures show I/O outlets on the eBOX630-528-FL. Front View 1 x VGA 1 x Reset switch 1 x 8-CH DIO 1 x Remote power switch 2 x Swappable HDD drive bay...
  • Page 20 Series User’s Manual Rear View 1 x Phoenix type power input 1 x COM 2 (RS232/422/485) 2 x LAN (i210IT) 1 x COM1 (RS232/422/485) 1 x LAN (i219LM) 1 x COM 3 (RS232) 2 x USB 3.1 gen 1 1 x COM 4 (RS232) 2 x USB 3.1 gen 2...

  • Page 21: Packing List

    1 VGA, 3 GbE LAN, 6 USB and 9 to 36 VDC Fanless embedded system with Intel ® Celeron 4305UE, eBOX630-528-FL-4305UE 2 HDMI, 1 VGA, 3 GbE LAN,6 USB and 9 to 36 VDC Please contact Axiomtek’s distributors immediately in case any abovementioned items are missing. Introduction...
  • Page 22 Series User’s Manual This page is intentionally left blank. Introduction...

  • Page 23: Section 2 Hardware Installation

    Series User’s Manual SECTION 2 HARDWARE INSTALLATION The eBOX630-528-FL is convenient for various hardware configurations, such as CPU, DRAM, HDD (Hard Disk Drive), SSD (Solid State Drive), PCI Express Mini card modules and optional MXM graphic module. Section 2 contains guidelines for hardware installation.
  • Page 24 Series User’s Manual Step 5 Please place the DRAM thermal pad on the module and screw the bracket. Step 6 Put the bottom cover back and fasten two screws back onto the system. Hardware Installation...

  • Page 25: Installation Of Mini Pcie Module (Full-Size)

    Series User’s Manual 2.2 Installation of Mini PCIe Module (Full-Size) Step 1 Turn off the system and unplug the power cord. Step 2 Turn the system upside down to locate screws at the bottom, and loosen two screws as red marked.
  • Page 26 Series User’s Manual Step 5 And then connect the cable to antenna opening. Step 6 Put the bottom cover and fasten all screws back onto the system. Hardware Installation...

  • Page 27: Installation Of 2.5" Sata Device

    Series User’s Manual 2.3 Installation of 2.5" SATA Device Step 1 Turn off the system and unplug the power cord. Step 2 Loosen two of the SATA drive tray’s screws and pull out the SATA HDD drive tray. Step 3 Turn the SATA drive tray upside down to install SSD/HDD and then fasten the four HDD screws to secure the SATA drive tray.

  • Page 28: Installation Of Sim Card

    Series User’s Manual 2.4 Installation of SIM Card Step 1 Turn off the system and unplug the power cord. Step 2 Loosen the screw of the SIM slot cover on chassis. Step 3 Make sure the SIM card direction is correct and insert the SIM card firmly.

  • Page 29: Section 3 Jumper & Connector Settings

    Series User’s Manual SECTION 3 JUMPER & CONNECTOR SETTINGS Proper jumper settings configure the eBOX630-528-FL to meet various application needs. Hereby all jumpers settings along with their default settings are listed for devices onboard. 3.1 Locations of Jumpers & Connectors SBC87528 Top View Jumper &...
  • Page 30 Series User’s Manual SBC87528 Bottom View 【Note】: It is strongly recommended that any unmentioned jumper settings should not be modified without instructions by Axiomtek FAEs. Any modifications without instructions might cause system failure. Jumper & Connector Settings...

  • Page 31: Summary Of Jumper Settings

    Series User’s Manual 3.2 Summary of Jumper Settings Proper jumper settings configure the eBOX630-528-FL to meet various application purposes. A table of all jumpers and their default settings is listed below. Jumpers Descriptions Settings Restore BIOS Optimal Defaults Short 1-2...

  • Page 32: Com1 Data/Power Selection (Jp3)

    Series User’s Manual 3.2.2 COM1 Data/Power Selection (JP3) This is a 2x3-pin (pitch=2.0mm) jumper. The COM1 port has +5V level power capability on DCD and +12V level on RI by setting jumper JP3. Functions Settings Power: Set CN21 pin 1 to +5V level...

  • Page 33: Connectors

    Series User’s Manual 3.3 Connectors Please refer to the below connector table to get information on pin assignments for individual connectors. External Connectors Sections DC-in Phoenix Power Connector 3.3.1 HDMI Connector 3.3.2 Serial Port Connector 3.3.3 USB 2.0 Connector 3.3.4...

  • Page 34: Dc-In Phoenix Power Connector (Cn20)

    Series User’s Manual 3.3.1 DC-in Phoenix Power Connector (CN20) The system supports 24V Phoenix DC-in connector for system power input. Pins Signals 3.3.2 HDMI Connector (CN14,CN15) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable.

  • Page 35: Serial Port Connector (Cn21,Cn22)

    Series User’s Manual 3.3.3 Serial Port Connector (CN21,CN22) The system has two serial ports. COM1~COM2 are RS-232/422/485 ports. Please refer to Chapter 4 for the details of BIOS settings. COM1 and COM2 is equipped with +5V level power capability on DCD and +12V level on RI by setting JP3 and JP4 (see section 2.3.2 and 2.3.3).

  • Page 36: Usb 3.1 Connector (Cn17,Cn18)

    Series User’s Manual 3.3.5 USB 3.1 Connector (CN17,CN18) The system has six USB ports: two ports compliant with USB 3.1 gen2 (10GB/s) , two ports compliant with USB 3.1 gen1 (5GB/s), and are ideal for installing USB peripherals such as scanners, cameras and USB devices, etc.

  • Page 37: Ethernet Connector (Lan1~Lan3)(Cn16,Cn19)

    Series User’s Manual 3.3.6 Ethernet Connector (LAN1~LAN3)(CN16,CN19) The board has three RJ-45 connectors. LAN1 is designed by Intel i219LM and LAN2 to LAN3 are Intel i210-IT. Pins LAN Signal Pins LAN Signal MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+ MDI1-...

  • Page 38: Vga Connector (Cn1)

    Series User’s Manual 3.3.7 VGA Connector (CN1) This is a standard 15-pin D-Sub connector. It is commonly used for VGA display. This VGA interface configuration can be configured via software utility. Signal Signal GREEN BLUE CRT_VCC DDC_DATA Hsync Vsync DDC_CLK 3.3.8...

  • Page 39: Remote Power Switch Connector (Pwrbt1)

    Series User’s Manual 3.3.10 Remote Power Switch Connector (PWRBT1) One 2-pin connector output for remote power on/off switch. * Connector specification: Male / Female: BTX 2P 3.0mm Functions Descriptions Short (1-2) Turn on/off system Open Keep system status 3.3.11 AT/ATX Switch If you set AT/ATX switch to AT mode, the system will automatically power on without the need to press the soft power button during power input;...

  • Page 40: Sim Card Slot (Cn4)

    Series User’s Manual 3.3.13 SIM Card Slot (CN4) The eBOX630-528 includes one SIM slot on the front panel of the system for inserting a SIM card. It is mainly used in 3G/LTE wireless network application on CN4. Pins Signals 3.3.14 SATA Connector (SATA 1 &...

  • Page 41: Full-Size Pci Express Mini Card Slot (Cn6,Cn7)

    Series User’s Manual 3.3.16 Full-Size PCI Express Mini Card Slot (CN6,CN7) The eBOX630-528-FL supports dual full-size PCI-Express Mini Card slots.CN6 is applying to either PCI-Express or USB 2.0 signal, and complies with PCI-Express Mini Card Spec. V1.2. CN7 is applying to PCI-Express or SATA (mSATA) (via BIOS selection) and USB signals;...
  • Page 42 Series User’s Manual Pins Signals Signals WAKE# +3.3VSB No use +1.5V No use CLKREQ# No use No use REFCLK- No use REFCLK+ No use No use No use No use W_DISABLE# PERST# PE_RXN3/mSATA +3.3VSB SATA_RXP PE_RXP3/mSATA SATA_RXN +1.5V SMB_CLK...

  • Page 43: Section 4 Bios Setup Utility

    Series User’s Manual SECTION 4 BIOS SETUP UTILITY This section provides users with detailed descriptions in terms of how to set up basic system configurations through the BIOS setup utility. 4.1 Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 44: Main Menu

    Series User’s Manual 4.3 Main Menu The Main Menu screen is the first screen users see when entering the setup utility. Users can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 45: Advanced Menu

    Series User’s Manual 4.4 Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. Users can select any items in the left frame of the screen to go to sub menus: ►...
  • Page 46 Series User’s Manual Mini Card switch Use this to select Mini Card setting; default is “PCIE”. BIOS Setup Utility...
  • Page 47 Series User’s Manual Super IO Configurations Use this screen to select options for the Super IO Configurations, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 48 Series User’s Manual Serial Port 1 Select Mode Use this option to set RS-232/RS-422/RS-485 mode. BIOS Setup Utility...
  • Page 49 Series User’s Manual Serial Port 2 Use this option to set RS-232/RS-422/RS-485 mode. BIOS Setup Utility...
  • Page 50 Series User’s Manual Serial Port 3 Use this option to set RS-232 mode. BIOS Setup Utility...
  • Page 51 Series User’s Manual Serial Port 4 Use this option to set RS-232 mode. BIOS Setup Utility...
  • Page 52 Series User’s Manual Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU as well as system voltages (VCORE, +5V STBY, VBAT, +5V and +3.3V). BIOS Setup Utility...
  • Page 53 Series User’s Manual ACPI Settings Use this screen to select options for the ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. ACPI Sleep State When the sleep button is pressed, the system will be in the ACPI sleep state.
  • Page 54 Series User’s Manual Trust Computing If users install a security device, such as TPM, users will see the following information for the TPM device and status. BIOS Setup Utility...
  • Page 55 Series User’s Manual CPU Configuration This screen shows the CPU version and its detailed information. Hyper-Threading Use this item to enable or disable Hyper-Threading Technology, which makes a single physical processor perform multi-tasking functions as two logical ones. ®...
  • Page 56 Series User’s Manual SATA & RST Configuration The SATA controller of the system supports two (2) operating modes: AHCI and Intel RST. SATA Controller Enable or disable the SATA Controller feature. The default is Enabled. SATA Mode Selection AHCI (Advanced Host Controller Interface) mode is how SATA controller(s) operate.
  • Page 57 Series User’s Manual PCH-FW Configuration This screen shows ME Firmware information. BIOS Setup Utility...
  • Page 58 Series User’s Manual AMT Configurations Users can use this screen to configure AMT parameters. Intel AMT Enable or disable Intel Active Management Technology BIOS Extension. ® The default is enabled. BIOS Setup Utility...
  • Page 59 Series User’s Manual USB Configurations Display all detected USB devices. BIOS Setup Utility...
  • Page 60 Series User’s Manual S5 RTC Wake Configurations Enable or disable System wake on alarm event. When Fixed Time is selected, system will wake at the time specified as “hr::min::sec”. When Dynamic Time is selected, system will wake at the current time + Increase minutes.
  • Page 61 Series User’s Manual Device Configurations This item allows users to set the Digital I/O to Input or Output. Default is 4 IN & 4 OUT. BIOS Setup Utility...

  • Page 62: Chipset Menu

    Series User’s Manual 4.5 Chipset Menu The Chipset menu allows users to change the advanced chipset settings. Users can select any of the items in the left frame of the screen to go to the sub menus: ► System Agent (SA) Configurations ►...
  • Page 63 Series User’s Manual System Agent (SA) Configurations This screen allows users to configure System Agent (SA) parameters. For items marked with “”, please press <Enter> for more options. Memory Configuration Use this item to refer to the information related to system memory.
  • Page 64 Series User’s Manual Memory Configurations This screen shows the system memory information. BIOS Setup Utility...
  • Page 65 Series User’s Manual PCH-IO Configurations This screen allows users to set PCH parameters. BIOS Setup Utility...
  • Page 66 Series User’s Manual Security Menu Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled). BIOS Setup Utility...

  • Page 67: Boot Menu

    Series User’s Manual 4.6 Boot Menu The Boot menu allows users to change boot options of the system. Setup Prompt Timeout Use this item to set up number of seconds to wait for setup activation key where 65535(0xFFFF) means indefinite waiting.

  • Page 68: Save & Exit Menu

    Series User’s Manual 4.7 Save & Exit Menu The Save & Exit menu allows users to load system configurations with optimal or fail-safe default values. Save Changes and Exit When users have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 69 Series User’s Manual Save Changes Having completed the system configuration changes, select this option to save changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes to save changes. Discard Changes Select this option to quit Setup without making any permanent changes to the system configurations.
  • Page 70 Series User’s Manual This page is intentionally left blank. BIOS Setup Utility...

  • Page 71: Appendix Awatchdog Timer

    Series User’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer Software stability is major issue in most applications. Some embedded systems are not watched by human for 24 hours. It is usually too slow to wait for someone to reboot when a computer hangs.

  • Page 72: Sample Program

    Series User’s Manual Sample Program The following example enables configurations using a debug tool. Enable WDT  Enable configuration: O 2E 87; Un-lock super I/O O 2E 87  Select logic device: O 2E 07 O 2F 08 ...
