Installation of SO-DIMM Memory
Step 1 Turn off the system, and unplug the power adaptor.
Step 2
Turn the system upside down to locate screws at the bottom,
and then loosen all screws.
Step 3 Located the SO-DIMM socket on main board.
Step 4
Locate the memory module, insert a gold colored contact into
the socket and push the module two end latches till locked.
Note: Please refer to the user's manual to get more detail information.
4
©Copyright 2017 Axiomtek Co., Ltd.
Version A2 May 2017
Printed in Taiwan
9416K100010E
eBOX100-312-FL Quick Installation Guide
Packing List
System Unit x 1
DVD/CD x 1 (for Driver & Manual)
Quick Installation Guide x 1
HDD Rubber x 1
US power cord x 1 or
36W power adapter x 1
EU power cord x 1
Foot pad x 4 (pre-install)
Do not try to apply power to the system if any damaged components.
Dimensions
©Copyright 2017 Axiomtek Co., Ltd.
Version A2 May 2017
Printed in Taiwan
9416K100010E
