  • Page 1 Series Embedded System User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permissions of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The eBOX565-312-FL does not come with an operating system which must be loaded first before installation of any software into the computer. Be sure to ground yourself to prevent static charge when installing any internal components.

  • Page 4: Classification

    Classification Degree of production against electric shock: not classified Degree of protection against ingress of water: IP40 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Mode of operation: Continuous...

  • Page 5: General Cleaning Tips

    General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner to absorb dirt on the floor.

  • Page 6: Scrap Computer Recycling

    Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Precautions ....................iii Classification ......................iv General Cleaning Tips ................... v Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION .................. 1 General Description ................1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 I/O System ......................
  • Page 8 Advanced Menu ................29 Chipset Menu ................... 43 Security Menu .................. 47 Boot Menu ..................48 Save & Exit Menu ................49 APPENDIX A WATCHDOG TIMER ..............51 About Watchdog Timer ................... 51 How to Use Watchdog Timer ................51 Sample Program ....................

  • Page 9: Section 1 Introduction

    Series User’s Manual SECTION 1 INTRODUCTION This section contains general information and detailed specifications of the eBOX565-312-FL. The Section 1 includes the following sections:  General Description  System Specifications  Dimensions  I/O Outlets  Packing List ...

  • Page 10: System Specifications

    Series User’s Manual  Reliable and Stable Design ® ® ® The embedded system supports Intel Pentium N4200(optional)/Celeron N3350, high flexibility and multi-functional design is the best solution for any industrial field applications.  Embedded O.S. Supported The eBOX565-312-FL supports not only Windows 10 but also embedded OS, such as Windows 10 Embedded and Linux.

  • Page 11: System Specification

    Series User’s Manual 1.2.3 System Specification  Watchdog Timer  1~255 seconds or minutes; up to 255 levels.  Power Supply  Input : 12VDC  Operation Temperature  -20℃~+50℃ (-4°F ~ +122°F), with W .T. SSD & Memory ...

  • Page 12: Dimensions

    Series User’s Manual Dimensions The following diagrams show dimensions and outlines of the eBOX565-312-FL. 1.3.1 System Dimensions Introduction...

  • Page 13: Wall Mount Bracket Dimensions

    Series User’s Manual 1.3.2 Wall mount Bracket Dimensions Introduction...

  • Page 14: Din-Rail Mount Bracket Dimensions

    Series User’s Manual 1.3.3 Din-rail mount Bracket Dimensions Introduction...
  • Page 15 Series User’s Manual 1.3.4 VESA mount Bracket Dimensions Introduction...

  • Page 16: I/O Outlets

    Series User’s Manual I/O Outlets The following figures show I/O outlets on front of the eBOX565-312-FL.  Front View  Rear View Introduction...

  • Page 17: Packing List

    N4200 eBOX565-312-FL-DC-N4200 2.5 GHz, 2 HDMI, 1 GbE LANs, 1 CH PSE, 4 USB 3.0, 2 COM, PCI Express Mini Card slot and 12 VDC power input Please contact Axiomtek’s distributors immediately in case any abovementioned items are missing. Introduction...
  • Page 18 Series User’s Manual This page is intentionally left blank. Introduction...

  • Page 19: Section 2 Hardware Installation

    Series User’s Manual SECTION 2 HARDWARE INSTALLATION The eBOX565-312-FL is convenient for your various hardware configurations, such as HDD (Hard Disk Drive), SSD (Solid State Drive), SO-DIMM or PCI Express Mini Card modules. The section 2 will show how to install the hardware.
  • Page 20 Series User’s Manual Step 4 Located SSD/HDD within the red line marked. Step 5 Please prepare the following items to assemble SSD/HDD. Step 6 Fasten four screws to fix HDD/SSD. Step 7 Connected the SSD/HDD directly and make sure the insertion is complete.

  • Page 21: Installation Of Express Mini Card

    Series User’s Manual Installation of Express Mini Card Step 1 Turn off the system, and unplug the power adaptor. Step 2 Turn the system upside down to locate screws at the side of the system, and then loosen two screws.
  • Page 22 Series User’s Manual Step 5 Slide Mini Card into Mini Card slot with caution, and fasten screw of Express Mini Card. Step 6 Recover the HDD cover and bottom cover, and then fasten two screws on the side of the system.
  • Page 23 Series User’s Manual Installation of SO-DIMM Memory Step 1 Turn off the system, and unplug the power adaptor. Step 2 Turn the system upside down to locate screws at the side of the system, and then loosen two screws.
  • Page 24 Series User’s Manual This page is intentionally left blank. Hardware Installation...

  • Page 25: Section 3 Jumper & Connector Settings

    Series User’s Manual SECTION 3 JUMPER & CONNECTOR SETTINGS Proper jumper settings configure the eBOX565-312-FL to meet various application needs. Hereby all jumpers settings along with their default settings are listed for devices onboard. Locations of Jumpers & Connectors...
  • Page 26 Series User’s Manual AX93728 AX98220 【Note】: It is strongly recommended that any unmentioned jumper settings should not be modified without instructions by Axiomtek FAEs. Any modifications without instructions might cause system failure. Jumper & Connector Settings...

  • Page 27: Summary Of Jumper Settings

    Series User’s Manual Summary of Jumper Settings Proper jumper settings configure the eBOX565-312-FL to meet various application purposes. A table of all jumpers and their default settings is listed below. PICO312: Jumper and Switch Descriptions Settings LVDS +3.3V/+5V/+12V Voltage Selection 1-2 Close Default: +3.3V...

  • Page 28: Atx/At Quick Switch

    Series User’s Manual 3.2.2 ATX/AT Quick Switch If SW1 is enabled for power input, the system will be automatically power on without pressing soft power button. If SW1 is disabled for power input, it is necessary to manually press soft power button to power on the system.

  • Page 29: Connectors

    Connectors connect the board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a summary table shows all connectors and button on the eBOX565-312-FL Series. Connectors...

  • Page 30: Power Input-Phoenix Type (Cn12)

    Series User’s Manual 3.3.1 Power Input-phoenix type (CN12) The eBOX565-312-FL equips with a screw type power connector. The CN12 is a DC jack (Φ2.5) with screw. Firmly insert approximately 60W/12V adapter into this connector. Loose connection may cause system instability and make sure all components/devices are properly installed before connecting.

  • Page 31: Hdmi Connector (Cn13)

    Series User’s Manual 3.3.3 HDMI Connector (CN13) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable. Pins Signals Pins Signals HDMI_OUT_DAT HDMI_OUT_DAT HDMI_OUT_DAT HDMI_OUT_DAT...

  • Page 32: Usb 3.0 Connector

    Series User’s Manual CN7A Signals Pins Data Carrier Detect (DCD) Receive Data (RXD) Transmit Data (TXD) Data Terminal Ready (DTR) Ground (GND) Data Set Ready (DSR) Request to Send (RTS) Clear to Send (CTS) Ring Indicator (RI) 3.3.5 USB 3.0 Connector The Universal Serial Bus connectors are compliant with USB 3.0 (5Gb/s), and ideally...

  • Page 33: System Power Switch

    Series User’s Manual 3.3.6 System Power Switch This button is for turning on/off the system power. Function Description Turn on/off system Keep system status 3.3.7 System Reset Switch This button reboots your computer without turning off the power supply. It is a better way to reboot your system for a longer life of the system power supply.

  • Page 34: Express Mini Card Slot (Scn1)

    Series User’s Manual 3.3.8 Express Mini Card Slot (SCN1) This is a PCI-Express Mini Card connector on the bottom side supporting PCI-Express x1 or SATA and USB 2.0. It complies with PCI-Express Mini Card Spec. V1.2. To enable or disable SATA for mSATA card, please refer to BIOS setting in section 4.4.

  • Page 35: Section 4 Bios Setup Utility

    Series User’s Manual SECTION 4 BIOS SETUP UTILITY This section provides users with detailed description how to set up basic system configuration through the BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del> key immediately.

  • Page 36: Main Menu

    Series User’s Manual Main Menu The Main Menu screen is the first screen users see when entering the setup utility. Users can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below. The Main BIOS setup screen is also shown below.

  • Page 37: Advanced Menu

    Series User’s Manual Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 38 Series User’s Manual  Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, system voltages (VBAT, +3.3V, +3.3V_SBY and +5V). BIOS Setup Utility...
  • Page 39 Series User’s Manual ACPI Settings Users can use this screen to select options for the ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 40 Series User’s Manual  Trusted Computing This screen provides function for specifying the TPM settings. Security Device Support Enable or disable BIOS support for security device. The default setting is Enable. TPM Device Enable or disable TPM device that supports TPM 1.2 specifications.
  • Page 41 Series User’s Manual  CPU Configuration This screen shows the CPU Configuration and you can change the value of the selected option. Socket 0 CPU Information Socket specific CPU information. Intel Virtualization Technology Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine Mode) can utilize the additional hardware capabilities.
  • Page 42 Series User’s Manual  CPU Configuration BIOS Setup Utility...
  • Page 43 Series User’s Manual  SATA Configuration This screen shows the CPU Configuration and you can change the value of the selected option. Chipset SATA Enable or disable the SATA chipset. Port 0~1 Enable or disable SATA port 0~1. MiniCard Switch Choose PCIE or mSATA for PCI-Express Mini Card.
  • Page 44 Series User’s Manual  USB Configurations USB Devices Display all detected USB devices. BIOS Setup Utility...
  • Page 45 Series User’s Manual  Utility Configuration BIOS Flash Utility BIOS flash utility configuration. For more detailed information, please refer to Appendix B. BIOS Setup Utility...
  • Page 46 Series User’s Manual  Device Configurations A description of selected item appears on the right side of the screen. For items marked with “ , please press <Enter> for more options. Module Device Configuration This option appears only if an I/O board is installed. BIOS will auto-detect all supported functions and you can use it to change settings on the I/O board.
  • Page 47 Series User’s Manual  Module Device configure This screen is available only if an I/O board with serial ports is connected. For items marked with “”, please press <Enter> for more options. BIOS Setup Utility...
  • Page 48 Series User’s Manual  AxiomType3 Super IO Configure BIOS Setup Utility...
  • Page 49 Series User’s Manual  Serial Port 1 Serial Port Enable or disable serial port 1 on I/O board. The optimal setting for base I/O address is 3F8h and for interrupt request address is IRQ4. COM Port Type Use this item to set RS-232/422/485 communication mode.
  • Page 50 Series User’s Manual  Serial Port 2 Serial Port Enable or disable serial port 2 on I/O board. The optimal setting for base I/O address is 2F8h and for interrupt request address is IRQ3. COM Port Type Use this item to set RS-232/422/485 communication mode.

  • Page 51: Chipset Menu

    Series User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. Users can select any of the items in the left frame of the screen to go to the sub menus: ► North Bridge For items marked with “”, please press <Enter>...
  • Page 52 Series User’s Manual  North Bridge This screen allows users to configure parameters of North Bridge chipset. Memory Information Show the information related to system memory. BIOS Setup Utility...
  • Page 53 Series User’s Manual Note: The LVDS option can only be selected in Primary IGFX Boot Display. Primary IGFX Boot Display Select the video device which will be activated during POST (Power-On Self Test). -With no I/O board connected, the default is LVDS.
  • Page 54 Series User’s Manual Secondary IGFX Boot Display Select secondary display device. -With no I/O board connected, the default is display device on PICO312 (onboard HDMI or onboard VGA). -With I/O board connected, the default is display device on I/O board (VGA on AX93A00 or HDMI on AX93A01).

  • Page 55: Security Menu

    Series User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled).

  • Page 56: Boot Menu

    Series User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.

  • Page 57: Save & Exit Menu

    Series User’s Manual Save & Exit Menu The Save & Exit menu allows users to load system configuration with optimal or fail-safe default values. Save Changes and Exit When users have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 58 Series User’s Manual Save Changes When completed the system configuration changes, select this option to save changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes to save changes. Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration.

  • Page 59: Appendix Awatchdog Timer

    Series User’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer Software stability is major issue in most application. Some embedded systems are not watched by human for 24 hours. It is usually too slow to wait for someone to reboot when computer hangs.

  • Page 60: Sample Program

    Series User’s Manual Sample Program Assembly sample code: ;Enable WDT: dx,2Eh al,87 ;Un-lock super I/O dx,al dx,al ;Select Logic device: dx,2Eh al,07h dx,al dx,2Fh al,08h dx,al ;Activate WDT: dx,2Eh al,30h dx,al dx,2Fh al,01h dx,al ;Set Second or Minute :...
  • Page 61 Series User’s Manual al,0F6h dx,al dx,2Fh al,Mh ;M=00h,01h,...FFh (hex),Value=0 to 255 Note dx,al ;(see below ;Disable WDT: dx,2Eh al,30h dx,al dx,2Fh al,00h ;Can be disabled at any time dx,al 【Note】: If N=00h, the time base is set to second.
  • Page 62 Series User’s Manual This page is intentionally left blank. Watchdog Timer...
