Installation, cont'd
14
15
16
17
18
19
20
21

Installation Overview

To install the scan converter, follow these general steps:
1
2
3
4
5
6
7
8
9
www.camboard.de
2-4 VSC 200/200D/300/300D Installation
CAMBOARD Electronics
RGB/R-Y, Y, B-Y LED — Lights to indicate that the RGB or component video
output is active.
Component video (R-Y, Y, B-Y) is referred to as YUV in the front panel LCD
menus.
Sync selection switch — Allows you to choose how the sync output signals
for RGsB/RGBS/RGBHV are routed:
H — If the switch is set to H, the scan converter outputs separate horizontal
and vertical sync signals; only horizontal sync is routed through the
H/HV output connector.
HV — If the switch is set to H/V, the scan converter outputs a composite sync
signal (H and V combined) on the H/HV output connector.
SOG — If the switch is set to SOG (sync on green), the scan converter outputs
a composite sync signal on the green video signal via the G/Y output
connector.
V output connector — Vertical sync output (RGBHV).
15-pin VGA output connector (VSC 300/300D only) — Scaled VGA output.
VGA LED (VSC 300/300D only) — Lights to indicate that the VGA output is
active.
Genlock input connector — Genlock reference signal input.
Genlock output connector — Passes the genlock reference signal to the next
device. If the signal is not passed to another device, connect a 75-ohm
termination adapter.
RS-232 connector — 9-pin D female connector that allows you to attach a
computer or controlling device for remote control of the scan converter.
If desired, mount the scan converter in a rack (see "Mounting the scan
converter" on page 2-5). Otherwise, install the rubber feet (see "Tabletop/
desktop placement" on page 2-6).
Turn off power to the input and output devices, and unplug the power cables
from them.
Attach the input device and the output device to the scan converter. See
"Cabling" on page 2-6.
Set the configuration switches.
Plug the scan converter, input device, and output device into a grounded AC
source.
Turn on the input and output devices.
Use the LCD menu screens to configure the scan converter. See "Front Panel
Operation", page 3-2.
The image from the input device should appear on the output device. If it
does not, double check steps 3 and 4 and make adjustments as needed. See
chapter 5 for additional assistance.
Optimize the image for your display environment. See "Optimizing the
image" on page 3-5.
