Vsc 300/300D - Extron electronics VSC 200 User Manual

im Vertrieb von
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Program control ........................... Extron's Simple Instruction Set™ – SIS™
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 30 watts, internal, auto-switchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Rack mount ................................... Yes, with included kit
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 17.1" W x 9.5" D (1U high, full rack width)
Product weight
VSC 200 ............................. 5.6 lbs (2.5 kg)
VSC 200 D ......................... 5.7 lbs (2.6 kg)
Shipping weight ........................... 10 lbs (4.5 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.

VSC 300/300D

Video input
Number/signal type ................... 1 VGA, 1Mac analog RGBHV, RGBS, and RGsB
Connectors .................................... VGA ........... 1 15-pin HD female + adapter cables
Minimum/maximum level(s) .... Analog ....... 0V to 2V p-p with no offset at unity gain
Impedance .................................... 75 ohms/High Z (switchable)
Horizontal frequency .................. Autoscan 24 kHz to 100 kHz
Vertical frequency ....................... Autoscan 50 Hz to 120 Hz
Resolution range .......................... Autoscan 560 x 384 to 1600 x 1280
External sync (genlock) ............... 0.3V to 1.0V p-p
The color subcarrier adjustment range is ±180 degrees from 0 for a total adjustment range of 360
degrees.
Video processing
Encoder ......................................... 10 bit digital
Digital sampling .......................... 24 bit, 8 bits per color; 80 MHz
Colors ............................................ 16.8 million
Horizontal filtering ..................... 8 levels
Vertical filtering ........................... 10 levels
Encoder filtering .......................... 3 levels
www.camboard.de
CAMBOARD Electronics
Extron's control program for Windows®
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
4.4 cm H x 43.4 cm W x 24.1 cm D
Mac ............ 1 15-pin D female
Tel. 07131 911201
VSC 200/200D/300/300D Specifications
Fax 07131 911203
ce-info@camboard.de
A-3
