Extron SHR BNC cables are super high resolution BNC cables. Extron recommends
that when using signals with a scanning frequency of 15–125 kHz and running
distances of 100 feet or more, high resolution BNC cables should be used to achieve
maximum performance.
Extron Part
SHR bulk cable
Bulk SHR-1, 500'
Bulk SHR-1, 1000'
Bulk SHR-4, 500'
Bulk SHR-5, 500'
BNC SHR crimp connectors, qty. 50
BNC-4 mini-HR bulk cable
Bulk BNC 4-500' HR
Bulk BNC 4-1000' HR
BNC 5 mini-HR bulk cable
Bulk BNC 5-500' HR
Bulk BNC 5-1000' HR
BNC 5 plenum mini-HR bulk cable
Bulk BNC 5-500' HRP
Bulk BNC 5-1000' HRP
Install plenum bulk cable
Bulk Install Plenum, 500'
Bulk Install Plenum, 1000'
Extron Part
BNC connectors
BNC mini-HR crimp connectors, qty. 50
BNC SHR crimp connectors, qty. 50
BNC bulkhead connectors, qty. 50
(for custom wall plates)
BNC-4 HR cable is used for RGBS cable runs and BNC-5 is used for RGBHV cable
runs. Either type can also be used for composite video, S-video, or RGB with sync
on green. All Extron BNC cables have male gender connectors at both ends. A
plenum version of the BNC-5 HR cable is also available.
Extron Part
BNC-4 HR cable
BNC-4-25'HR (25 feet/7.5 meters)
BNC-4-50'HR (50 feet/15.0 meters)
BNC-4-75'HR (75 feet/23.0 meters)
BNC-4-100'HR (100 feet/30.0 meters)
BNC-4-150'HR (150 feet/45.0 meters)
BNC-4-200'HR (200 feet/60.0 meters)
BNC-4-250'HR (250 feet/75.0 meters)
BNC-4-300'HR (300 feet/90.0 meters)
Tel. 07131 911201
VSC 200/200D/300/300D Reference Information
Fax 07131 911203
Part #
22-098-02
22-098-03
22-099-02
22-100-02
100-075-51
22-032-02
22-032-03
22-020-02
22-020-03
22-103-02
22-103-03
22-111-03
22-111-04
Part #
100-074-51
100-075-51
100-076-51
Part #
26-210-04
26-210-05
26-210-06
26-210-07
26-210-08
26-210-09
26-210-54
26-210-53
Continued on the next page
