7.4.2 Calibrate Board

Initial calibrating of each analog input channel is done at the factory by selecting each channel, one at a
time, and applying 20mA. The analog input board self-adjusts its output, and stores this value in non-
volatile memory.

7.5 Analog Outputs

If the ViewSmart 1600+ is equipped with an analog output option board the output can be manually
stimulated by selecting the channel group, then the channel, to be ramped up. Pressing the Edit increases
the output value in 4mA increments from 0mA to 20mA.
Analog Output
Analog Output Ch.01-08
Analog Output Ch.09-16

7.6 Piezo

Selecting Piezo pulses the controller's local Piezo buzzer.
UM-1097
Revision B
~
~
Figure 59 Analog Output Diagnostics Menu
P i e z o B e e p T e s t .
" N e x t " T o
B E E P !
Analog Output Ch.01-08
Analog Out 1
Analog Out 2
Analog Out 3
Analog Out 4
Analog Out 5
" " "
Analog Out 8
P r e s s
E x i t .
8mA
4mA
12mA
20mA
16mA
"
0mA
